DigitroniK Line
SDC20/21
Digital Indicating Controller
User's Manual
No. CP-UM-1470E

This product has been designed, developed and manufactured for general-purpose
application in machinery and equipment.
Accordingly, when used in applications outlined below, special care should be taken to
implement a fail-safe and/or redundant design concept as well as a periodic
maintenance program.
• Safety devices for plant worker protection
• Start/stop control devices for transportation and material handling machines
• Aeronautical/aerospace machines
• Control devices for nuclear reactors
Never use this product in applications where human safety may be put at risk.
RESTRICTIONS ON USE
The above is a registered trademark of Yamatake Corporation.
Other company names and product names listed in this manual are registered
trademarks or trademarks of respective companies.
REQUEST
©1993 Yamatake Corporation ALL RIGHTS RESERVED
Ensure that this User's Manual is handed over to the user before the
product is used.
Copying or duplicating this User's Manual in part or in whole is forbid-
den. The information and specifications in this User's Manual are sub-
ject to change without notice.
Considerable effort has been made to ensure that this User's Manual is
free from inaccuracies and omissions.
If you should find any inaccuracies or omissions, please contact
Yamatake Corporation.
In no event is Yamatake Corporation liable to anyone for any indirect,
special or consequential damages as a result of using this product.

i
SAFETY REQUIREMENTS
To reduce risk of electric shock which could cause personal injury, follow all safety notices in
this documentation.
This symbol warns the user of a potential shock hazard where hazardous live voltages may be
accessible.
* If the equipment is used in a manner not specified by the manufacturer, the protection provided by the
equipment must be impaired.
* Do not replace any component (or part) not explicitly specified as replaceable by your supplier.
* All wiring must be in accordance with local norms and carried out by authorized experienced personnel.
* The ground terminal must be connected before any other wiring (and disconnect last).
* A switch in the main supply is required near the equipment.
* In case of AC power supply models, mains power supply wiring requires a (T) 0.5 A, 250 V fuse(s).
Installation category: Category II (IEC664-1, EN61010-1)
Specification of common mode voltage: The common mode voltages of all I/O except for main supply and
relay outputs are less than 30V rms, 42.4 V peak and 60V dc.
EQUIPMENT RATINGS
Supply voltage 85 to 264 Vac
Frequency 50/60 Hz
Power or current ratings 18 VA maximum
EQUIPMENT CONDITIONS
Do not operate the instrument in the presence of flammable liquids or vapors. Operation of any electrical
instrument in such an environment constitutes a safety hazard.
Temperature 0 to 50°C
Humidity 10 to 90% RH
Vibration Frequency 10 to 60 Hz
Acceleration 2 m/s
2
maximum
EQUIPMENT INSTALLATION
The controller must be mounted into a panel to limit operator access to the rear terminals.

ii
WARNING
• Before connecting or disconnecting wiring to or from this product, be sure to
turn the mains power supply OFF. Inadvertently touching terminals or other
electrically live parts might cause electric shock.
• Before connecting this product to the measurement target or external control
circuits, make sure that it is connected to an earth. Failure to do so might
cause electric shock or fire.
CAUTION
• Wire this product properly in accordance with predetermined wiring standards, in-
struction described in this manual and generally accepted wiring methods. Failure to
do so might result in electric shock, fire or malfunction.
• Use this product only within the recommended operating conditions (temperature,
humidity, voltage, vibration, shock, atmosphere, etc.) described in the specifications.
• Do not cover the ventilation holes on this product. Doing so might result in fire or
malfunction.
• Do not disassemble this product, or touch parts inside. Doing so might result in elec-
tric shock or malfunction.
• Some parts in this product become hot while the power is turned ON or are hot
immediately after the power is turned OFF. Do not touch these parts. Doing so might
result in burns.
• Do not operate the operation keys on this product with the top of a propelling pencil or
other sharp-tipper object. Doing so might result in malfunction.
Safety Precautions
This manual describes how to use this product. Before using this product, thoroughly read
and understand the descriptions in this manual to ensure correct use.
After you have read this manual, store the manual a safe place nearby so that it can be
referred whenever need.

Contents
iii
Safety Precautions
Chapter 1 NAMES AND FUNCTIONS OF COMPONENT PARTS......................... 1-1
Chapter 2 INSTALLATION...................................................................................... 2-1
2-1 SDC20 External Dimensions.............................................................................................. 2-1
2-2 SDC20 Panel Cutout Sizes ................................................................................................ 2-2
2-3 SDC21 External Dimensions.............................................................................................. 2-3
2-4 SDC21 Panel Cutout Dimensions ...................................................................................... 2-4
2-5 Mounting ............................................................................................................................ 2-5
■ Location of mounting..................................................................................................... 2-5
■ Mounting method .......................................................................................................... 2-5
2-6 External Dimensions of Current Transformer .................................................................... 2-6
Chapter 3 WIRING...................................................................................................3-1
3-1 Cables ................................................................................................................................ 3-2
3-2 Terminal Connections ........................................................................................................ 3-3
3-3 Terminal Arrangement ....................................................................................................... 3-4
3-4 Power Supply Connections ............................................................................................... 3-4
3-5 Grounding .......................................................................................................................... 3-5
3-6 Input Connection ............................................................................................................... 3-5
3-7 Output Connection............................................................................................................. 3-6
3-8 Connection of Remote Switch(option) ............................................................................... 3-7
3-9 Connection of Current Transformer (CT, option) .............................................................. 3-7
3-10 Communication Connection .............................................................................................. 3-8
3-11 Wiring Precautions ........................................................................................................... 3-10
3-12 Countermeasures Against Noise ..................................................................................... 3-10
Chapter 4 SETTING THE SETUP ITEMS ...............................................................4-1
4-1 Setup Operation ................................................................................................................. 4-1
4-2 Setup Table ........................................................................................................................ 4-2
4-3 Basic Operation for Setup ................................................................................................. 4-3
4-4 Description on the Setup Items ......................................................................................... 4-5
Chapter 5 SETTING OF PARAMETERS ................................................................5-1
5-1 Parameters Table............................................................................................................... 5-1
5-2 Basic Parameter Operation ............................................................................................... 5-2
5-3 Assigning a Parameter to the
PARA
Key ........................................................................ 5-3
5-4 Resetting a Parameter Assigned to the
PARA
Key ........................................................ 5-4
5-5 Operation of Parameters Assigned ................................................................................... 5-5
5-6 Description on Parameters ................................................................................................ 5-6
Chapter 6 OPERATION........................................................................................... 6-1
6-1 Turning on the Power Supply ............................................................................................ 6-2
6-2 Indicating a PV ................................................................................................................... 6-4
6-3 Indicating an SP................................................................................................................. 6-4
6-4 Indicating the Output Value ............................................................................................... 6-5
6-5 Indicating the Heater Current Value (optional) ................................................................. 6-6
6-6 Changing an SP (with single SP)....................................................................................... 6-7
6-7 Changing an SP (with multi SP) ......................................................................................... 6-8
6-8 Selecting the SP of Multi SP .............................................................................................. 6-9
6-9 Changing the Set Value of Event (optional) .................................................................... 6-10
剩余99页未读,继续阅读
