General Description

The MAX9286 Gigabit multimedia serial link (GMSL)

deserializer receives data from up to four GMSL serial-

izers over 50Ω coax or 100Ω shielded twisted pair (STP)

cables and output data on four CSI-2 lanes. Each serial

link has an embedded control channel operating from

9.6kbps to 1Mbps in UART-UART, UART-I

C, and I

C-I

mode. Using the control channel, a µC can program the

serializers, deserializer, and peripheral device registers at

any time, independent of video timing. A maskable broad-

cast write speeds programming of image sensor registers.

For use with longer cables, the deserializer has a pro-

grammable cable equalizer and programmable error

detection and correction. The serial input meets ISO

10605 and IEC 61000-4-2 ESD standards. The core sup-

ply is 1.7V to 1.9V and the I/O supply is 1.7V to 3.6V.

The device is available in lead(Pb)-free, 56-pin, 8mm x

8mm QFND and TQFN packages with exposed pad and

0.5mm lead pitch.

Applications

● Surround View Camera Systems

● Machine Vision Systems

● 3D Camera Systems

Benets and Features

● Ideal for Multicamera Stream Applications

• Works with Low-Cost 50Ω Coax Cable and FAKRA

Connectors or 100Ω STP

• Data from Image Sensors Are Synchronized to the

Same Pixel

• Automatic Internal/External Generation of Camera

Sync

• Equalization Allows 15m Length Cable Operation

at Full Speed

● Multiple Input/Output Features for System Flexibility

• 1 to 4 Lane CSI-2 Output with 80Mbps to

1200Mbps Per Lane

• Swappable/Selectable Serial Input/Output with

Swappable Polarity

• 9.6kbps to 1Mbps Control Channel in UART,

Mixed UART/I

C, or I

C Mode with Clock Stretch

Capability

● Peripheral Features for System Power-Up and

Verification

• Built-In PRBS Tester for BER Testing of the

Serial Link

• Programmable Choice of Nine Default Device

Addresses

• Two Dedicated GPIO Ports

• High-Immunity Mode for Maximum Control-

Channel Noise Rejection

● Meets Rigorous Automotive and Industrial

Requirements

• -40°C to +105°C Operating Temperature

• ±8kV Contact, ±20kV Air ISO 10605 and ±8kV

Contact, ±12kV EC 61000-4-2 ESD Protection

Ordering Information appears at end of data sheet.

19-7456; Rev 0; 1/15

MAX9286 Quad 1.5Gbps GMSL Deserializer with Coax

or STP Input and CSI-2 Output

MAX9286 Quad 1.5Gbps GMSL Deserializer with Coax

or STP Input and CSI-2 Output

www.maximintegrated.com

Maxim Integrated

│

TABLE OF CONTENTS

General Description ............................................................................ 1

Applications

.................................................................................. 1

Features and Benefits

.......................................................................... 1

Absolute Maximum Ratings

...................................................................... 7

Package Thermal Characteristics

................................................................. 7

DC Electrical Characteristics

..................................................................... 7

AC Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Typical Operating Characteristics

................................................................ 15

Pin Configuration

............................................................................. 17

Pin Description

............................................................................... 17

Functional Diagram

........................................................................... 19

Detailed Description

........................................................................... 25

...........................................................................25

Frame Combination

..........................................................................26

Serial Link Signaling and Data Format

...........................................................26

Maximum Input/Output Data Rate

..............................................................30

Data Formats and Configuration

................................................................30

Supported Data Rates

.......................................................................47

Reverse Control Channel

.....................................................................47

Control Channel and Register Programming

......................................................47

UART Interface

.............................................................................48

Interfacing Command-Byte-Only I

C Devices with UART .........................................50

UART Bypass Mode

......................................................................50

C Interface ...............................................................................50

START and STOP Conditions

...............................................................51

Bit Transfer

..............................................................................51

Acknowledge

............................................................................51

Slave Address

...........................................................................52

Bus Reset

...............................................................................52

Format for Writing

........................................................................52

Format for Reading

.......................................................................53

C Communication with Remote Side Devices .................................................53

UART/I

C Device Address Translation...........................................................53

Line Equalizers

.............................................................................54

HS/DE Tracking

.............................................................................54

Cable Type Configuration

.....................................................................54

High-Immunity Reverse Control Channel Mode

...................................................54

Sleep Mode

................................................................................55

MAX9286 Quad 1.5Gbps GMSL Deserializer with Coax

or STP Input and CSI-2 Output

www.maximintegrated.com

Maxim Integrated

│

TABLE OF CONTENTS (CONTINUED)

Power-Down Mode ..........................................................................55

Frame Sync

................................................................................55

Internal Frame Sync (FSYNCMODE = 0X)

.....................................................55

External Frame Sync (FSYNCMODE = 1X)

.......................................................55

GPO/GPI Control

...........................................................................55

Configuration Link

...........................................................................55

Link Masking

...............................................................................55

Link Startup Procedure

........................................................................ 56

Applications Information

........................................................................ 58

Self-PRBS Test

.............................................................................58

Error Checking

.............................................................................58

ERR Output

................................................................................58

Auto Error Reset

............................................................................58

Changing the Clock Frequency

.................................................................59

Software Programming of the Device Addresses

...................................................59

3-Level Configuration Inputs

...................................................................59

Configuration Blocking

.......................................................................59

Compatibility with Other GMSL Devices

.........................................................59

HS/VS Inversion

............................................................................59

GPIOs

....................................................................................59

Internal Input Pulldowns

......................................................................59

Choosing I

C/UART Pullup Resistors ...........................................................60

AC-Coupling

...............................................................................60

Selection of AC-Coupling Capacitors

............................................................60

Selection of Camera Frequency References

......................................................60

Power-Supply Circuits and Bypassing

...........................................................60

Cables and Connectors

......................................................................61

Board Layout

...............................................................................61

ESD Protection

.............................................................................61

Typical Application Circuit

...................................................................... 82

Ordering Information

.......................................................................... 82

Chip Information

.............................................................................. 82

Package Information

.......................................................................... 82

Revision History

.............................................................................. 83

MAX9286 Quad 1.5Gbps GMSL Deserializer with Coax

or STP Input and CSI-2 Output

www.maximintegrated.com

Maxim Integrated

│

LIST OF FIGURES

Figure 1. Reverse Control Channel Output Parameters ............................................... 20

Figure 2. Test Circuit for Differential Input Measurement

.............................................. 20

Figure 3. Test Circuit for Single-Ended Input Measurement

............................................ 20

Figure 4. Line Fault

........................................................................... 21

Figure 5. Worst-Case Pattern Output

............................................................. 22

Figure 6. I

C Timing Parameters ................................................................. 22

Figure 7. Deserializer Delay

..................................................................... 23

Figure 8. GPI-to-GPO Delay

.................................................................... 23

Figure 9. Lock and Camera Sync Time

............................................................ 23

Figure 10. Power-Up Delay

..................................................................... 24

Figure 11. MIPI Output Timing Parameters

......................................................... 24

Figure 12. Frame Combination

.................................................................. 26

Figure 13. 24-Bit Mode Serial Data Format

......................................................... 27

Figure 14. 32-Bit Mode Serial Data Format

......................................................... 28

Figure 15. 27-Bit High-Bandwidth Mode Serial Data Format

........................................... 29

Figure 16. RAW8 Input Map

..................................................................... 31

Figure 17. RAW10 Input Map

.................................................................... 32

Figure 18. RAW11x2 Input Map

.................................................................. 33

Figure 19. RAW12 Input Map

.................................................................... 34

Figure 20. RAW12x2 Input Map

.................................................................. 35

Figure 21. RAW14 Input Map

.................................................................... 36

Figure 22. RAW16 Input Map

.................................................................... 37

Figure 23. RAW20 Input Map

................................................................... 38

Figure 24. YUV8 Input Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Figure 25. YUV10 Input Map

.................................................................... 40

MAX9286 Quad 1.5Gbps GMSL Deserializer with Coax

or STP Input and CSI-2 Output

www.maximintegrated.com

Maxim Integrated

│

LIST OF FIGURES (CONTINUED)

Figure 26. YUV12 Input Map .....................................................................41

Figure 27. RGB565 Input Map

................................................................... 42

Figure 28. RGB666 Input Map

................................................................... 43

Figure 29. RGB888 Input Map

................................................................... 44

Figure 30. User-Defined 8-Bit Input Map

........................................................... 45

Figure 31. User-Defined 24-Bit Input Map

.......................................................... 46

Figure 32. GMSL UART Protocol for Base Mode

.................................................... 48

Figure 33. GMSL UART Data Format for Base Mode

................................................. 49

Figure 34. Sync Byte (0x79)

..................................................................... 49

Figure 36. Format Conversion Between GMSL UART and I

C with Register Address (I2CMETHOD = 0)........ 49

Figure 35. ACK Byte (0xC3)

..................................................................... 49

Figure 37. Format Conversion Between GMSL UART and I

C Without Register Address (I2CMETHOD = 1) ..... 50

Figure 38. START and STOP Conditions

.......................................................... 51

Figure 39. Bit Transfer

......................................................................... 51

Figure 40. Acknowledge

........................................................................ 51

Figure 41. Slave Address

....................................................................... 52

Figure 42. Format for I

C write .................................................................. 52

Figure 43. Format for I

C Write to Multiple Registers ................................................. 52

Figure 44. Format for I

C Read .................................................................. 53

Figure 45. Example Frame Sync Operation (Automatic Mode)

.......................................... 56

Figure 46. State Diagram

....................................................................... 58

Figure 47. Human Body Model ESD Test Circuit

..................................................... 61

Figure 49. ISO 10605 Contact Discharge ESD Test Circuit

............................................ 61

Figure 48. IEC 61000-4-2 Contact Discharge ESD Test Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

剩余82页未读，继续阅读

zengwj2014

粉丝: 0
资源: 2

会员权益专享

MAX9286.pdf

评论0

会员权益专享

最新资源

MAX9286.pdf

评论0

max9286.pdf

MAX9286 GTN.PDF

MAX9288-MAX9290.pdf

Maxim_MAX9286_Datasheet_Rev0_201501.pdf

MAX9288COAXEVKIT-MAX9290COAXEVKIT.pdf

MAX96705COAXEVKIT-MAX96711COAXEVKIT.pdf

MAX9295配置说明.pdf

MAX1480A-MAX1490B 中文数据手册.pdf

Microprocessor Design Vhdl.pdf

MAX485 TTL转485芯片.pdf

max30102心率血氧模块使用说明.pdf 道客

Pro Core Data for iOS.pdf

使用Nios II处理器通过UART接口对Max10 FPGA器件进行远程系统更新.pdf

SQL示例大全.pdf

hadoop_the_definitive_guide_3nd_edition.pdf

3dmax场景建模pdf

PX4模式切换流程图commander.cpp.pdf

DeepDive教程2.pdf

基于DAQmx的模拟电压生成与采集系统设计.pdf

会员权益专享

最新资源
