S32 SDK Quick Start Guide, Rev. 1.6, 06/2018

NXP Semiconductors 1

S32 SDK Quick Start Guide

Document Number: S32 SDK QSG

Rev. 1.6, 06/2018


S32 SDK Quick Start Guide, Rev. 1.6, 06/2018
NXP Semiconductors  2
Introduction .......................................................................................................................... 3
1 System requirements .................................................................................................. 3
2 Installing S32 SDK ..................................................................................................... 3
3 Release Notes ............................................................................................................. 4
4 Terminology ............................................................................................................... 4
Working with Projects .......................................................................................................... 5
1 Creating and building S32DS project ........................................................................ 5
2 Importing an existing project ..................................................................................... 9
3 Using New Project From Example .......................................................................... 11
4 Using a Makefile Project .......................................................................................... 12
5 Debugging Projects .................................................................................................. 13
6 Graphical Configuration of Drivers ......................................................................... 15


S32 SDK Quick Start Guide, Rev. 1.6, 06/2018

NXP Semiconductors 3

Chapter 1

Introduction

The S32 Software Development Kit (S32 SDK) is an extensive suite of robust hardware

interface and hardware abstraction layers, peripheral drivers, RTOS, stacks and

middleware designed to simplify and accelerate application development on NXP S32K

microcontrollers.

This manual explains how to use the S32 SDK product, including the use with S32 Design

Studio, for easier application creation and configuration with graphical user interface.

1.1 System requirements

Hardware

• 1.8 GHz processor

• 2 GB of RAM

Operating System

Microsoft® Windows® 7.

Gnu Make

For usage without S32 Design Studio.

Supported Compiler

For usage without S32 Design Studio. See release

notes for supported versions.

Disk Space

Approximately 2 GB of free disk space (when

installing standalone)

NOTE

The S32 Design Studio software development tools requirements

are covered by their own Quick Start Guide. PEx graphical

configuration tool can only be used with S32 Design Studio.

1.2 Installing S32 SDK

1.2.1 Bundled in S32 Design Studio

S32 SDK is delivered bundled in the S32 Design Studio. In this case it’s already configured

and ready to use.

1.2.2 Standalone

S32 SDK is also delivered through a standalone installer. Using the standalone installer is

recommended when using a compiler which is not supported in S32 Design Studio or

S32 SDK Quick Start Guide, Rev. 1.6, 06/2018

NXP Semiconductors 4

when the graphical interface is not required. In this case the installer can configure an

existing S32 Design Studio to use the configuration files delivered in the installer.

If the integration with the S32 Design Studio is not needed the path to S32 Design Studio

can be left empty – and in this case, only the S32 SDK will be installed and configured.

1.3 Release Notes

Before using the S32 SDK, read the release notes. These notes contain important

information about last-minute changes, bug fixes, incompatible elements, or other topics

that may not be included in this manual. The product comes with the release notes

installed.

1.4 Terminology

The following are some of the terms used in the document.

Table 1-1. Terminology

Term

Description

S32 SDK

Software development kit that provides comprehensive software support for

NXP S32 devices. The S32 SDK includes a Hardware Abstraction Layer (HAL)

for each peripheral and peripheral drivers built on top of the HAL. S32 SDK

also contains the latest available RTOS kernels, a LIN stack and SBC

middleware to support rapid development on supported S32K devices.

Processor Expert

Rapid application design tool targeted for NXP microcontrollers providing the

following key features:

• A Graphical User Interface which allows an application to be specified by

the functionality needed.

• An application created from Embedded Components encapsulating

initialization and functionality of basic elements of embedded systems.

• An automatic code generator which creates tested and optimized C code

which is tuned to your application needs and the selected NXP device.

• A built-in knowledge base, which immediately flags resource conflicts and

incorrect settings, so errors are caught early in design cycle allowing you

to get to market faster with a higher quality product.
