Abstract
The method of 3D human body modeling is critical to the 3D virtual try on system,
and it will influence the complexity and effect of garment’s simulation directly. Also now
garment computer aided design system is shifting from two-dimension design to three-
dimension design. Therefore studying the method 3D human body has extensive value in
research and prospect for application. In this thesis, the method of parameterized 3D
human body modeling is developed. The following matter is involved.
First, current obtaining 3D human body surface information is discussed。 According
to the traits and the feasibility of 3D virtual try on system, the method of combining the
traditional method of osculating measurement in costume industry with standard human
body template library is put forward. In order to obtain a accurate virtual body , In except
the basic parameter is provided by the client ,such as chest girth, waist girth, hip girth,
stature and etc，also additional characteristic size parameter need be provided, such as the
thickness and width of the chest, the distance of the breast, the height of the breast, the
thickness of the hip. Then the reconstructed 3D virtual human body can be more vivid and
realistic.
The surface information of 3D human body must be obtained before constructing the
library of virtual human body. Because of the experiment conditions, the human body
model is constructed by the professional 3D character design software Poser 6.0, the data
of human model is exported in 3DS file format, then according to the structure of 3ds file
type, we work out a program to acquire the surface vertex information of mannequin. The
format of 3DS file also is introduced simply.
There were many methods for 3D human body modeling purpose, such as Line
framing, curved surface, solid and physical-based modeling methods, In the thesis,
because accurate geometric surface, vivid appearance and easily modified virtual human
