OV13850&1300万像素OV影像传感器.pdf

The OV13850 color image sensor is a low voltage, high performance 1/3.06-inch 13.2 megapixel CMOS image sensor that provides the functionality of a single 13.2 megapixel (4224×3136 ) camera using OmniBSI+ ? technology. It provides full-frame, sub-sampled, windowed 10-bit MIPI images in various formats via the control of the Serial Camera Control Bus (SCCB) interface. The OV13850 has an image array capable of operating at up to 24 frames per second (fps) in 10-bit 13.2megapixel resolution with complete user control over image quality, formatting and output data transfer. All required image processing functions, including exposure control, white balance, defective pixel canceling, etc., are programmable through the SCCB interface.
