基于大数据爬虫的全国空气质量指数实时数据可视化基于大数据爬虫的全国空气质量指数实时数据可视化
from lxml import etree
import urllib
import urllib.request
import xlwt
import pandas as pd
from pyecharts import Geo
import matplotlib.pyplot as plt
import matplotlib as mpl
def getpage(url):
req=urllib.request.Request(url)
req.add_header('User-Agent') #添加自己的用户代理
data=urllib.request.urlopen(req).read().decode("gbk")
return data
def getdata(data):
AQI=[] start=0
html=etree.HTML(data)
infor=html.xpath('//li[@id!="tr-fixed"]//text()') #利用xpath解析路径
while True:
if start<len(infor):
AQI.append(infor[start:start+5])
start=start+5
else:
break
return AQI
#写入excel表格
def writeExcel(AQI):
f=xlwt.Workbook()
sheet1=f.add_sheet('The AQI',cell_overwrite_ok=True)
rowTitle=['order','city','province','AQI','quality'] for i in range(len(rowTitle)):
sheet1.write(0,i,rowTitle[i])
for j in range(len(AQI)):
for k in range(len(AQI[j])):
sheet1.write(j+1,k,AQI[j][k])
f.save("E:\python\aqi.xls")
if __name__=="__main__":
url="http://tianqi.2345.com/air-rank.htm"
data=getpage(url)
AQI=getdata(data)
writeExcel(AQI)
city=[];value=[] fbook=pd.DataFrame(pd.read_excel("E:\python\aqi.xls",0))
for each in fbook['city']:
city.append(str(each))
for each in fbook['AQI']:
value.append(each)
for order,quality in zip(fbook['order'],fbook['quality']):
if quality=="中度污染":
index=order-1
break
geo = Geo("全国空气质量指数", "Data from AQI", title_color="#fff", width=1000, height=600, \
background_color='#404a59')
geo.add("空气质量指数", city,value, visual_range=[1,60], maptype='china', type='effectScatter', \
visual_text_color="#fff",effect_scale=5,symbol_size=15, is_visualmap=True,is_random=True,is_roam=False)
geo.render(path="全国空气质量指数.html")
fig=plt.figure()
ax=fig.add_subplot(111)
rects = ax.bar(range(len(city)-index),value[index:],tick_label=city[index:],color='r')
plt.grid()
plt.xlabel('城市')
plt.ylabel('空气质量指数')
plt.title("中度污染、重度污染、严重污染城市")
mpl.rcParams["font.sans-serif"] = ["KaiTi"] mpl.rcParams["axes.unicode_minus"] = False
plt.show()
