INCA V7.0
Integrated Measurement, ECU Calibration and
Diagnostic Environment
The tools of the INCA product family form an
integrated environment for measurement, ECU
calibration and diagnostics. The tools are used
for ECU development and test as well as for
validation and calibration of electronically
controlled systems on the test bench and in
the vehicle.
INCA offers a wide variety of functions rang-
ing from precalibration of function models on
the PC, ECU flash programming, measurement
data analysis, calibration data management to
automated optimization of ECU parameters. The
generated calibration and measurement data
can be processed and evaluated continuously.
ECU calibration can be prepared offline and
performed online during continuous operation.
INCA supports a great number of compact,
automotive-proven measurement devices and
interface modules which allow the access to
ECUs, buses and sensors. Signals from the ECU,
as well as from bus lines (LIN, CAN, FlexRay)
or measurement devices are synchronously
acquired, displayed and recorded.
The numerous innovations and improvements
of the new version 7.0 increase the efficiency
and performance of the tools on one hand.
On the other hand, INCA V7.0 offers new pos-
sibilities for integrating tools and data in the
development environment of the customer.
Standards and open interfaces
For the seamless integration into the develop-
ment environment, INCA comes with a number
of open interfaces. INCA V7.0 is compliant with
the new specification for exchanging measure-
ment data, ASAM MDF4, and with the latest
versions of the ASAM standards MCD-2 MC
(ECU description for measurement and cali-
bration systems) and MCD-3 MC (test bench
interface). INCA V7.0 is the only tool currently
New Functions at a Glance
Flexible interface for connecting calibration
data base systems
Easy integration of customer-specific
instruments
Open interface for calibration data
documentation
Easy configuration of complex experiments
Graphical comparison of characteristic curves
Recording of GPS data
Support of the new interface modules ES592,
ES593-D, ES595 and the drive recorder ES720
Automatic testing of firmware versions of
the connected hardware modules
Support of Windows
®
7
