Copyright 2018 Sony Semiconductor Solutions Corporation
1
Diagonal 28.3 mm (Type 1.8
) CMOS Image Sensor with Square Pixel for Color
Cameras
IMX571BQR-C
Description
The IMX571BQR-C is a diagonal 28.3 mm (Type 1.8) CMOS active pixel type image sensor with a square pixel array
and 26.11 M effective pixels. This sensor incorporates maximum 36 dB PGA circuit and 16-bit A/D converter. 16-bit
digital output makes it possible to readout the signals of 26.11 M effective pixels at high-speed of 6.84 frame/s in still
picture mode. In addition, it realizes 12-bit digital output for high-speed 4K moving picture by window readout mode.
This sensor is designed for use in consumer use digital still camera. When using this for another application, Sony
Semiconductor Solutions Corporation does not guarantee the quality and reliability of this product. Therefore, don’t
use this for applications other than consumer use digital still camera.
In addition, individual specification change cannot be supported because this is a standard product.
Consult your Sony Semiconductor Solutions Corporation sales representative if you have any questions.
Features
◆ APS size CMOS active pixel type dots
◆ Input clock frequency 72 MHz
◆ All-pixel readout mode
All-pixel readout mode / 2-parallel ADC readout
All-pixel readout mode / digital overlap drive
Vertical 2/2-line and horizontal 2/2-line weighted binning readout mode
Vertical 1/3 subsampling, horizontal 3 weighted binning readout mode
Vertical 3/3-line binning, horizontal 3 weighted binning readout mode
Vertical 1/3 subsampling, horizontal 3 weighted binning readout mode / digital overlap drive
Vertical 3/3-line binning, horizontal 3 weighted binning readout mode / digital overlap drive
Vertical 1/5 subsampling, horizontal 3 weighted binning readout mode
Vertical 3/5 subsampling binning, horizontal 3 weighted binning readout mode
Vertical 1/7 subsampling, horizontal 3 weighted binning readout mode
Vertical 3/7 subsampling binning, horizontal 3 weighted binning readout mode
Vertical 1/9 subsampling, horizontal 3 weighted binning readout mode
Vertical 3/9 subsampling binning, horizontal 3 weighted binning readout mode
Vertical 1/13 subsampling, horizontal 3 weighted binning readout mode
Vertical 3/13 subsampling binning, horizontal 3 weighted binning readout mode
Vertical 1/25 subsampling, horizontal 3 weighted binning readout mode
Vertical 3/25 subsampling binning, horizontal 3 weighted binning readout mode
◆ Rolling shutter function moving picture mode
◆ H driver, V driver and serial communication circuit on chip
◆ +36dB gain in CDS/PGA on chip (when A/D 16-bit, 14-bit, 12-bit)
◆ Built-in 11-bit/12-bit/14-bit/16-bit A/D converter
◆ 8 Lane SLVS-EC output
◆ R, G, B primary color mosaic filter on chip
◆ Back-illuminated type
Sony Semiconductor Solutions Corporation reserves the right to change products and specifications without prior notice.
This information does not convey any license by any implication or otherwise under any patents or other right.
Application circuits shown, if any, are typical examples illustrating the operation of the devices. Sony Semiconductor Solutions
Corporation cannot assume responsibility for any problems arising out of the use of these circuits.
E18Z05B97
CONFIDENTIAL
