Getting Started
Introduction
The Angle of Arrival BoosterPack™ kit (BOOSTXL-AOA) is an easy-to-use plug-in module equipped with antenna arrays
suitable for evaluation of Angle of Arrival applications. The 2 orthogonal antenna arrays each consist of 3 dipole
antennas tuned for operation at 2.4 GHz. The antennas are selected with RF switches and then connected to a single
JSC connector. The JSC Series connector is used to connect to an AoA compatible RF receiver like the CC2640R2
LaunchPad™.
Key Features
Two antenna arrays with three 2.4
GHz dipole antennas on each
RF switches to switch between the
different antennas
JSC RF connector
Two LEDs
What's Included
1x BOOSTXL-AoA
1x 100 mm JSC to JSC RF cable
1x Quick Start Guide
Requirements
BOOSTXL-AoA is designed to be used with the CC2640R2 LaunchPad and are following the BoosterPack™ Module
d d
Meet the Angle of Arrival
BoosterPack™
