2017/1/10 Zhhans:MapFeaturesOpenStreetMapWiki
http://wiki.openstreetmap.org/wiki/Zhhans:Map_Features 1/71
· 帮助
Zh-hans:Map Features
来自OpenStreetMap Wiki
可用语言 — Map Features
· asturianu · azәrbaycanca · Bahasa Indonesia · bosanski · català · čeština · dansk · Deutsch · eesti · English · español · Esperanto
· français · hrvatski · íslenska · italiano · Kreyòl ayisyen · kréyòl gwadloupéyen · latviešu · lietuvių · magyar · Nederlands
· norsk bokmål · polski · português · română · shqip · slovenčina · slovenščina · suomi · svenska · Tiếng Việt · Türkçe · српски/srpski
· български · македонски · русский · українська · Ελληνικά · ქართული · தழ் · 한국어 · 日本語 · 中文(简体) · 中文(繁體) · תירבע
· ﺔﻴﺑﺮﻌﻟﺍ · ﯽﺳﺭﺎﻓ
其他语言 (https://wiki.openstreetmap.org/wiki/Zh-hans:Map_Features) — 帮助我们翻译这个wiki
OpenStreetMap 在资料元素 (点 , 路径 或是 关系 )。的标签(tags)使用上并无任何限制,你可以选用任何你想使用的标签。可是,如各
OpenStreetMap用户在建议使用的设施标签(features)及相关标签作出共识,会对编辑地图起帮助。此条目列出了建议使用设施及相关标签。
如果你未能在此条目找到适当的标签,你可以前往Proposed features(拟议设施标签)。你可以在那里作出增加设施标签的建议。要将一群路径和点构
成更高等及的组合,可疑查看关系页面。
Some mapping features are explained in detail, see Feature Index.
To propose a new icon, use the page of the Proposed Icons.
To see a list of features that were once valid but should no longer be used, see Deprecated features.
recent Map Features changes
请参考编辑标准和协定
特别提醒:
使用这里所描述的标签代表你的编辑将会出现在有可能会出现在绘制出的地图上。但是这并不保证这里的所有标签都会被所有的绘图工具绘制在地
图上。请参考Symbol Rendering 查看有哪些标签会被Mapnik 和Osmarender 绘制出来。
有许多会被绘制在地图上的标签并没有列在这里。这个列表并没有同步列出所有绘图工具所支持的标签。
'图上显示' 栏的图只是示意图,并不代表绘图工具一定会将这个标签的资料会制成这样子。
The tables are grouped by theme, with the more commonly used first.
Each section is a template which can be used for language translations.
目录
1 自然
1.1 公路
1.1.1 道路
1.1.2 Link roads
1.1.3 Special road types
1.1.4 小径
1.1.5 Lifecycle
1.1.6 Attributes
1.1.7 其它特点
1.2 Barrier
1.2.1 Linear barriers
1.2.2 Access control on highways
1.3 Cycleway
1.4 路径类型
1.5 Waterway
1.5.1 Natural watercourses
1.5.2 Man made waterways
1.5.3 Facilities
1.5.4 Barriers on waterways
1.5.5 Other features on waterways
1.5.6 Some additional attributes for waterways
1.6 铁路
1.6.1 轨道
1.6.2 其它特征
1.6.3 车站
1.6.4 铁路有关设施
1.7 机场道路
1.8 Aerialway
1.9 Power
1.10 Man_made
1.11 Leisure
1.12 设施(Amenity)
1.12.1 餐饮设施
1.12.2 教育設施
1.12.3 交通設施
1.12.4 金融設施
1.12.5 醫療設施
1.12.6 娛樂、藝術與文化設施
1.12.7 其他設施
1.13 Shop
1.13.1 Food, beverages
1.13.2 General store, department store, mall
1.13.3 Clothing, shoes, accessories
1.13.4 Discount store, charity

2017/1/10 Zhhans:MapFeaturesOpenStreetMapWiki
http://wiki.openstreetmap.org/wiki/Zhhans:Map_Features 2/71
1.13.5 Health and beauty
1.13.6 Do-it-yourself, household, building materials, gardening
1.13.7 Furniture and interior
1.13.8 Electronics
1.13.9 Outdoors and sport, vehicles
1.13.10 Art, music, hobbies
1.13.11 Stationery, gifts, books, newspapers
1.13.12 Others
1.14 Tourism
1.15 Historic
1.16 土地利用
1.17 Military
1.18 Natural
1.18.1 Vegetation or surface related
1.18.2 Water related
1.18.3 Landform related
1.19 Geological
2 非自然
2.1 路线
2.2 Boundary
2.2.1 Attributes
2.3 Sport
2.4 Abutters
2.5 Properties
2.6 Restrictions
3 命名
3.1 Name
3.2 References
3.3 Places
3.3.1 Administratively declared places
3.3.2 Populated settlements, urban
3.3.3 Populated settlements, urban and rural
3.3.4 Other places
3.3.5 Additional attributes
3.4 Addresses
3.4.1 Tags for individual houses
3.4.2 For countries using hamlet, subdistrict, district, province, state
3.4.3 Tags for interpolation ways
3.5 Annotation
自然
公路
Highway 为用于街道的最主要标签。它往往是唯一的标记。在特定国家使有其用的公约。参见 Highway tag usage 和 Road 页获得指导。

2017/1/10 Zhhans:MapFeaturesOpenStreetMapWiki
http://wiki.openstreetmap.org/wiki/Zhhans:Map_Features 3/71
类别(key) 值(value) 元素 说明 图上显示 照片
道路
These are the principal tags for the road network. They range from the most to least important.
highway motorway
高速公路/快速公路。为全封闭或半封闭、出入口控制的道路,
通常至少有2条车道。
highway trunk 主干道路/城市快速路
highway primary 主要道路。连接主要区域/城镇的道路。
highway secondary 次要道路。连接主要区域的道路,但不及主要道路重要。
highway tertiary 普通街道。
highway unclassified 未分类道路(最普通的道路,通常很窄)
highway residential 进入或靠近住宅区的道路。
highway service
通往建筑物、公路服务站、海滩、营地、校园、工业区、商业
园等的服务道路。不常被称为胡同。
Link roads
highway motorway_link 通往高速公路/快速公路的道路/出入口。
highway trunk_link 连接主干道路与其他主干道路或较低级道路的连接路。

2017/1/10 Zhhans:MapFeaturesOpenStreetMapWiki
http://wiki.openstreetmap.org/wiki/Zhhans:Map_Features 4/71
highway primary_link 连接主要道路与其他主要道路或较低级道路的连接路。
highway secondary_link 连接次要道路与其他次要道路或较低级道路的连接路。
highway tertiary_link
The link roads (sliproads/ramps) leading to/from a
tertiary road from/to a tertiary road or lower class
highway.
Special road types
highway living_street 行人有优先权,儿童可以在街上玩,最高速度较低的街道。
highway pedestrian
行人专用街道(步行街)或行人专用区。亦可作为广场的标签
用,唯须加上area=yes。
highway track 小径(通常未铺设路面)。
highway bus_guideway
公交专用车辆的引导轨道(不是铁路),不适合于其他交通工
具。请注意:这不是一条常规的巴士专线,用 access=no,
psv=yes 代替!
highway escape
For runaway truck ramps, runaway truck lanes, emergency
escape ramps, or truck arrester beds. It enables
vehicles with braking failure to safely stop.
highway raceway 比赛专用(赛车)车道
highway road
未知其分类的道路。此标签为临时标签,当找到道路的分类后
须以Highway其他标签取代。
小径
highway footway
主要为行人车或行人专用道路。这包括步行小径和砾石路。如
果允许自行车,你可以加入 bicycle=yes 标记表明。
highway bridleway 骑马道路。相当于 highway=path + horse=designated。

2017/1/10 Zhhans:MapFeaturesOpenStreetMapWiki
http://wiki.openstreetmap.org/wiki/Zhhans:Map_Features 5/71
highway steps 在人行道的楼梯(阶梯)。用 step_count=* 来表示阶梯数目。
highway path 一个非特定的或共享使用的路径。
When sidewalk (or pavement) is tagged on the main roadway (see Sidewalks)
sidewalk both / left / right / no
Specifies that the highways has sidewalks on both
sides, on one side or no sidewalk at all
When cycleway is drawn as its own way (see Bicycle)
highway cycleway
主要为自行车或自行车专用道路。只有 默认行驶方式限制 不
适用时才添加 foot=*。
Cycleway tagged on the main roadway or lane (see Bicycle)
cycleway lane A lane is a route that lies within the roadway
cycleway opposite
Used on ways with oneway=yes where it is legally
permitted to cycle in both directions. Used together
with oneway:bicycle=no.
cycleway opposite_lane
Used on ways with oneway=yes that have a cycling lane
going the opposite direction of normal traffic flow (a
"contraflow" lane). Used together with
oneway:bicycle=no.
cycleway track
A track provides a route that is separated from
traffic. In the United States, this term is often used
to refer to bike lanes that are separated from lanes
for cars by pavement buffers, bollards, parking lanes,
and curbs. Note that a cycle track may alternatively be
drawn as a separate way next to the road which is
tagged as highway=cycleway.
cycleway opposite_track
Used on ways with oneway=yes that have a cycling track
going the opposite direction of normal traffic flow
cycleway share_busway There is a bus lane that cyclists are permitted to use.
cycleway shared_lane
Cyclists share a lane with motor vehicles, but there
are markings indicating that they should share the lane
with motorists.
busway lane Bus lane on both sides of the road.
Lifecycle
highway proposed 计划修建的道路,和 proposed=* 搭配使用。
