PCB压合结构厚度解析_20200923 Desigh by Suwin 钟 1.了解基本换算 1oz厚度=1.4mil * 0.0254=0.035mm /1000 = 35um 1mil = 0.0254mm 1mm = 1000um 2.了解常用PP规格 PP ：Homopoly 聚丙烯均聚物 常用的PP型号 厚度（mil） 1080 2.5~3.2 2116 4.4~5.0 7628 7.0~8.5
