Legal information
S7-1500 / KUKA mxAutomation
Entry ID: 109482123, V1.2, 05/2018
2
Siemens AG
2018 All rights reserved
Legal information
Use of application examples
Application examples illustrate the solution of automation tasks through an interaction of several
components in the form of text, graphics and/or software modules. The application examples are
a free service by Siemens AG and/or a subsidiary of Siemens AG (“Siemens”). They are non-
binding and make no claim to completeness or functionality regarding configuration and
equipment. The application examples merely offer help with typical tasks; they do not constitute
customer-specific solutions. You yourself are responsible for the proper and safe operation of the
products in accordance with applicable regulations and must also check the function of the
respective application example and customize it for your system.
Siemens grants you the non-exclusive, non-sublicensable and non-transferable right to have the
application examples used by technically trained personnel. Any change to the application
examples is your responsibility. Sharing the application examples with third parties or copying the
application examples or excerpts thereof is permitted only in combination with your own products.
The application examples are not required to undergo the customary tests and quality inspections
of a chargeable product; they may have functional and performance defects as well as errors. It is
your responsibility to use them in such a manner that any malfunctions that may occur do not
result in property damage or injury to persons.
Disclaimer of liability
Siemens shall not assume any liability, for any legal reason whatsoever, including, without
limitation, liability for the usability, availability, completeness and freedom from defects of the
application examples as well as for related information, configuration and performance data and
any damage caused thereby. This shall not apply in cases of mandatory liability, for example
under the German Product Liability Act, or in cases of intent, gross negligence, or culpable loss of
life, bodily injury or damage to health, non-compliance with a guarantee, fraudulent
non-disclosure of a defect, or culpable breach of material contractual obligations. Claims for
damages arising from a breach of material contractual obligations shall however be limited to the
foreseeable damage typical of the type of agreement, unless liability arises from intent or gross
negligence or is based on loss of life, bodily injury or damage to health. The foregoing provisions
do not imply any change in the burden of proof to your detriment. You shall indemnify Siemens
against existing or future claims of third parties in this connection except where Siemens is
mandatorily liable.
By using the application examples you acknowledge that Siemens cannot be held liable for any
damage beyond the liability provisions described.
Other information
Siemens reserves the right to make changes to the application examples at any time without
notice. In case of discrepancies between the suggestions in the application examples and other
Siemens publications such as catalogs, the content of the other documentation shall have
precedence.
The Siemens terms of use (https://support.industry.siemens.com) shall also apply.
Security information
Siemens provides products and solutions with industrial security functions that support the secure
operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is necessary
to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept.
Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems, machines
and networks. Such systems, machines and components should only be connected to an
enterprise network or the Internet if and to the extent such a connection is necessary and only
when appropriate security measures (e.g. firewalls and/or network segmentation) are in place.
For additional information on industrial security measures that may be implemented, please visit
https://www.siemens.com/industrialsecurity.
Siemens’ products and solutions undergo continuous development to make them more secure.
Siemens strongly recommends that product updates are applied as soon as they are available
and that the latest product versions are used. Use of product versions that are no longer
supported, and failure to apply the latest updates may increase customer’s exposure to cyber
threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS Feed
at: https://www.siemens.com/industrialsecurity.

Table of Contents
S7-1500 / KUKA mxAutomation
Entry ID: 109482123, V1.2, 05/2018
3
Siemens AG
2018 All rights reserved
Table of Contents
Legal information ......................................................................................................... 2
1 Introduction ........................................................................................................ 5
1.1 Overview............................................................................................... 5
1.2 How it works ......................................................................................... 5
1.3 Aim of this Application Example ........................................................... 7
1.4 Components used ................................................................................ 7
2 Basics ................................................................................................................. 9
2.1 Configuration of an industrial robot ...................................................... 9
2.2 KUKA.PLC mxAutomation.................................................................. 10
2.2.1 Overview............................................................................................. 10
2.2.2 KUKA.PLC mxAutomation block library ............................................. 11
2.2.3 Interpreter on the KUKA robot controller ............................................ 11
2.3 Configuration of the block library ........................................................ 11
2.3.1 Block types ......................................................................................... 11
2.3.2 Block inputs and outputs .................................................................... 12
3 Creating a program .......................................................................................... 14
3.1 Hardware configuration ...................................................................... 14
3.1.1 Robot as PROFINET device .............................................................. 14
3.1.2 Installing the GSDML file of the robot ................................................ 14
3.1.3 Integrating a robot into the hardware configuration ........................... 16
3.1.4 Connecting the SIMATIC S7 and the robot ........................................ 18
3.1.5 Controlling several robots using a SIMATIC S7 ................................. 18
3.2 Importing a block library ..................................................................... 19
3.2.1 Unpacking a block library ................................................................... 19
3.2.2 Opening a block library ....................................................................... 19
3.2.3 Transferring blocks to the user program ............................................ 20
3.3 Basic program structure ..................................................................... 21
3.4 "SiemensKuka" block ......................................................................... 22
3.4.1 KRC_ReadAxisGroup ........................................................................ 23
3.4.2 KRC_WriteAxisGroup ......................................................................... 23
3.4.3 Function blocks for robot movements ................................................ 24
3.5 "KukaControl" function block .............................................................. 25
3.5.1 KRC_Initialize ..................................................................................... 27
3.5.2 KRC_ReadMXAStatus ....................................................................... 27
3.5.3 KRC_ReadKRCError .......................................................................... 28
3.5.4 KRC_Diag .......................................................................................... 29
3.5.5 KRC_ReadMXAError ......................................................................... 30
3.5.6 KRC_MessageReset .......................................................................... 31
3.5.7 KRC_AutomaticExternal..................................................................... 31
3.5.8 KRC_AutoStart ................................................................................... 32
3.5.9 KRC_SetOverride ............................................................................... 33
3.5.10 KRC_ReadActualPosition .................................................................. 34
3.5.11 KRC_ReadActualAxisPos .................................................................. 36
3.5.12 KRC_Jog ............................................................................................ 37
3.5.13 KRC_TouchUP ................................................................................... 38
3.6 "PickPlace" block ................................................................................ 39
3.6.1 KRC_Abort ......................................................................................... 41
3.6.2 KRC_Interrupt .................................................................................... 41
3.6.3 KRC_Continue ................................................................................... 41
3.6.4 mxA_ValuesToCOORDSYS .............................................................. 42
3.6.5 mxA_ValuesToAPO ........................................................................... 42
3.6.6 MC_MoveAxisAbsolute ...................................................................... 44
3.6.7 MC_MoveLinearAbsolute ................................................................... 46

Table of Contents
S7-1500 / KUKA mxAutomation
Entry ID: 109482123, V1.2, 05/2018
4
Siemens AG
2018 All rights reserved
3.7 "Circle" block ...................................................................................... 48
3.7.1 mxA_ValuesToE6POS ....................................................................... 50
3.7.2 MC_MoveDirectAbsolute.................................................................... 51
3.7.3 MC_MoveCircAbsolute ....................................................................... 52
3.8 Operation ............................................................................................ 55
3.8.1 Status bar and Override ..................................................................... 55
3.8.2 Control functions ................................................................................ 56
3.8.3 Jogging the robot ................................................................................ 57
3.8.4 Example Programs ............................................................................. 58
3.9 Error handling ..................................................................................... 59
3.9.1 HMI only shows rhombuses ............................................................... 59
3.9.2 No connection to the robot controller ................................................. 60
3.9.3 MxA interface is not initialized ............................................................ 60
3.9.4 The robot cannot be switched on ....................................................... 61
4 Additional function .......................................................................................... 62
4.1 Safety Integrated ................................................................................ 62
4.1.1 Components ....................................................................................... 62
4.1.2 Functionality ....................................................................................... 62
4.1.3 Control ................................................................................................ 62
4.2 Receive robot messages in plain text ................................................ 63
5 Appendix .......................................................................................................... 64
5.1 Advanced Example ............................................................................ 64
5.2 Service and support ........................................................................... 65
5.3 Contact partners ................................................................................. 66
5.3.1 KUKA Roboter GmbH ........................................................................ 66
5.3.2 KUKA Roboter GmbH Hotline ............................................................ 66
5.3.3 Sales and Marketing for KUKA.PLC mxAutomation .......................... 66
5.4 Links and Literature ............................................................................ 67
5.5 Change documentation ...................................................................... 68

1 Introduction
S7-1500 / KUKA mxAutomation
Entry ID: 109482123, V1.2, 05/2018
5
Siemens AG
2018 All rights reserved
1 Introduction
The use of industrial robots continues to grow. They are increasingly being used in
machines and plants. Their standardized mechanics are well-developed and highly
flexible in terms of their movement; as a result, robots are increasingly replacing
expensive specialist mechanics. This also enables production from the first
production batch without expensive modifications to machines and plants.
Unfortunately, plant controllers and robot controllers usually constitute two different
systems. Communication between the two controllers usually occurs solely on the
bit level and the movement programs of the robot are stored on the robot controller
and may only be called up by the plant controller. It is therefore difficult to trigger
flexible robot reactions to specific plant events.
Also, the plant controller and the robot are usually very different in terms of their
programming, which means that it is not possible for one person to control both
systems. Interface and coordination problems are therefore pre-programmed.
1.1 Overview
A complete integration of the actuation and the movement control of the robot into
the machine and plant controller should make the use of the industrial robot in a
production plant easier and more flexible.
The following requirements are imposed on the automation task:
• The robot should be fully programmable via the machine and plant controller
(PLC).
• The robot can be operated via the same HMI of the PLC/machine (Single Point
of Operation).
• Robot diagnostics should be fully possible via the PLC.
• It should be possible to integrate further functions such as Safety Integrated
and PROFIenergy and control them via the PLC.
1.2 How it works
A KUKA industrial robot is to be fully programmed and operated using a SIMATIC
S7-1500 controller. The KUKA.PLC mxAutomation block library in the TIA Portal is
used; this provides all the function blocks required for this purpose. Additional
programming of the robot controller is therefore not required.
Communication between the SIMATIC S7-1500 controller and the KUKA industrial
robot takes place via a PROFINET connection. All commands and status
information between the SIMATIC controller and the robot are exchanged via this
connection.
Note
With a SIMATIC S7-1500 controller, up to five KUKA industrial robots can be
simultaneously controlled in the TIA Portal using the KUKA.PLC mxAutomation
block library.
The Application Example presented here, however, is limited to the coupling of a
robot to a SIMATIC S7-1500.
剩余67页未读,继续阅读














安全验证
文档复制为VIP权益,开通VIP直接复制

评论5
