[Name]

Horizontal tab

[Format]

ASCII

Hex

Decimal

[Description]

Moves the print position to the next horizontal tab

position.

[Notes]

 This command is ignored unless the next horizontal

tab position has been set.

 If the next horizontal tab position exceeds the

print area, the printer sets the print position to

[Print area width + 1].

 If this command is processed when the print

position is at [Print area width + 1], the printer

executes print buffer-full printing of the current

line and horizontal tab processing from the

beginning of the next line. In this case, in Page

mode, the printer does not execute printing, but

the print position is moved.

 Horizontal tab positions are set by ESC D.

 The printer will not be in the beginning of the line

by executing this command.

 When underline mode is turned on, the underline

will not be printed under the tab space skipped by

this command.

[Models]

 TM-J2000

 TM-J2100

 TM-L90

 TM-P20

 TM-P60

 TM-P60II

 TM-P80

 TM-T20

 TM-T20II

 TM-T70

 TM-T70II

 TM-T82II

 TM-T88IV

 TM-T88V

 TM-T90

 TM-U220

 TM-U230

[Name]

Print and line feed

[Format]

ASCII

Hex

Decimal

[Description]

Prints the data in the print buffer and feeds one line,

based on the current line spacing.

[Notes]

 The amount of paper fed per line is based on the

value set using the line spacing command (ESC 2 or

ESC 3).

 After printing, the print postion is moved to left

side of the printable area. Also, the printer is

in the status "beginning of the line".

 When this command is processed in Page mode, only

the print position moves, and the printer does not

perform actual printing.

FF (in Page mode)

[Models]

 TM-J2000

 TM-J2100

 TM-L90

 TM-P20

 TM-P60

 TM-P60II

 TM-P80

 TM-T20

 TM-T20II

 TM-T70

 TM-T70II

 TM-T82II

 TM-T88IV

 TM-T88V

 TM-T90

 TM-U220

 TM-U230

[Name]

Print and return to Standard mode (in Page mode)

[Format]

ASCII

Hex

Decimal

[Description]

in Page mode, prints all the data in the print buffer

collectively and switches from Page modeto Standard mode.

[Notes]

 This command is enabled only in Page mode. See FF

(in Standard mode) to use this command in Standard

mode. Page mode can be selected by ESC L.

 The data is deleted in the print area after being

printed.

 This command returns the values set by ESC W to the

default values.

 The value set by ESC T is maintained.

 After printing, the printer returns to Standard

mode and moves the print position to left side of

the printable area. Also, the printer is in the

status "beginning of the line".

[Models]

 TM-J2000

 TM-J2100

 TM-L90

 TM-P20

 TM-P60

 TM-P60II

 TM-P80

 TM-T20

 TM-T20II

 TM-T70

 TM-T70II

 TM-T82II

 TM-T88IV

 TM-T88V

 TM-T90

 TM-U220

 TM-U230

[Name]

Print and carriage return

[Format]

ASCII

Hex

Decimal

[Description]

Executes one of the following operations.

Print head

alignment

When auto

line feed is

enabled

When auto line feed is

disabled

Horizontal

alignment

Executes

printing and

one line feed

as LF

This command is ignored.

Vertical

alignment

Executes

printing and

one line feed

as LF

In Standard mode, prints

the data in the print

buffer and moves the print

position to the beginning

of the print line.

in Page mode, moves the

print position to the

beginning of the print

line.

 [Horizontal alignment] is applied to Line thermal

head or Shuttle head.

 [Vertical alignment] is applied to Serial dot head.

[Notes]

 With a serial interface, the command performs as

if auto line feed is disabled.

 Enabling or disabling the auto line feed can be

selected by the DIP switch or the memory switch.

Memory switch can be changed with GS ( E <Function

3>;.

 After printing, the print postion is moved to left

side of the printable area. Also, the printer is

in the status "beginning of the line".

 When this command is processed in Page mode, only

the print position moves, and the printer does not

perform actual printing.

DLE EOT

[Models]

 TM-J2000

 TM-J2100

 TM-L90

 TM-P20

 TM-P60

 TM-P60II

 TM-P80

 TM-T20

 TM-T20II

 TM-T70

 TM-T70II

 TM-T82II

 TM-T88IV

 TM-T88V

 TM-T90

 TM-U220

 TM-U230

[Name]

Transmit real-time status

[Format]

ASCII

DLE

EOT

[a]

Hex

[a]

Decimal

[a]

[Range]

n, a: different depending on the printers

[Description]

Transmits the real-time status, using n as follows:

Function

−

Transmit Printer status

−

Transmit Offline cause status

−

Transmit Error cause status

−

Transmit Roll paper sensor

status

Transmit Ink status A

Transmit Ink status B

Transmit Peeler status
