UltraScale Architecture PCB Design 16

UG583 (v1.16) June 26, 2019 www.xilinx.com

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 294

Possibility 1: Excessive Noise from Other Devices on the PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .294

Possibility 2: Parasitic Inductance of Planes, Vias, or Connecting Traces . . . . . . . . . . . . . . . . . . . . . . . . . . . .295

Possibility 3: I/O Signals in PCB are Stronger Than Necessary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .296

Possibility 4: I/O Signal Return Current Traveling in Sub-Optimal Paths . . . . . . . . . . . . . . . . . . . . . . . . . . . .296

Chapter 12: Design of Transitions for High-Speed Signals

Excess Capacitance and Inductance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297

Time Domain Reflectometry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297

BGA Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299

SMT Pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300

Differential Vias . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 305

P/N Crossover Vias. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307

SMA Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307

Backplane Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307

Microstrip/Stripline Bends . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308

Appendix A: Memory Derating Tables

Appendix B: Material Properties and Insertion Losses

Appendix C: Additional Resources and Legal Notices

Xilinx Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323

Solution Centers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323

Documentation Navigator and Design Hubs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323

References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 324

Please Read: Important Legal Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325

Send Feedback

UltraScale Architecture PCB Design 17

UG583 (v1.16) June 26, 2019 www.xilinx.com

Chapter 1

Power Distribution System in

UltraScale Devices

Introduction to UltraScale Architecture

The Xilinx® UltraScale™ architecture is the first ASIC-class architecture to enable multi-

hundred gigabit-per-second levels of system performance with smart processing, while

efficiently routing and processing data on-chip. UltraScale architecture-based devices

address a vast spectrum of high-bandwidth, high-utilization system requirements by using

industry-leading technical innovations, including next-generation routing, ASIC-like

clocking, 3D-on-3D ICs, multiprocessor SoC (MPSoC) technologies, and new power

reduction features. The devices share many building blocks, providing scalability across

process nodes and product families to leverage system-level investment across platforms.

Virtex® UltraScale+™ devices provide the highest performance and integration capabilities

in a FinFET node, including both the highest serial I/O and signal processing bandwidth, as

well as the highest on-chip memory density. As the industry's most capable FPGA family,

the Virtex UltraScale+ devices are ideal for applications including 1+Tb/s networking and

data center and fully integrated radar/early-warning systems.

Virtex UltraScale devices provide the greatest performance and integration at 20 nm,

including serial I/O bandwidth and logic capacity. As the industry's only high-end FPGA at

the 20 nm process node, this family is ideal for applications including 400G networking,

large scale ASIC prototyping, and emulation.

Kintex® UltraScale+ devices provide the best price/performance/watt balance in a FinFET

node, delivering the most cost-effective solution for high-end capabilities, including

transceiver and memory interface line rates as well as 100G connectivity cores. Our newest

mid-range family is ideal for both packet processing and DSP-intensive functions and is well

suited for applications including wireless MIMO technology, Nx100G networking, and data

center.

Kintex UltraScale devices provide the best price/performance/watt at 20 nm and include

the highest signal processing bandwidth in a mid-range device, next-generation

transceivers, and low-cost packaging for an optimum blend of capability and cost-

effectiveness. The family is ideal for packet processing in 100G networking and data centers

Send Feedback

UltraScale Architecture PCB Design 18

UG583 (v1.16) June 26, 2019 www.xilinx.com

Chapter 1: Power Distribution System in UltraScale Devices

applications as well as DSP-intensive processing needed in next-generation medical

imaging, 8k4k video, and heterogeneous wireless infrastructure.

Zynq® UltraScale+ MPSoC devices provide 64-bit processor scalability while combining

real-time control with soft and hard engines for graphics, video, waveform, and packet

processing. Integrating an Arm®-based system for advanced analytics and on-chip

programmable logic for task acceleration creates unlimited possibilities for applications

including 5G Wireless, next generation ADAS, and Industrial Internet-of-Things.

This user guide describes the UltraScale architecture PCB design and pin planning resources

and is part of the UltraScale Architecture documentation suite available at:

www.xilinx.com/ultrascale.

Introduction

This chapter documents the power distribution system (PDS) for UltraScale devices,

including decoupling capacitor selection, placement, and PCB geometries. A simple

decoupling method is provided for each device. Basic PDS design principles are covered, as

well as simulation and analysis methods. This chapter contains the following sections:

• PCB Decoupling Capacitors

• Transceiver PCB Routing Guidelines

• Maximum Current Draw for V

CCINT in Virtex UltraScale+ Devices

PCB Decoupling Capacitors

Recommended PCB Capacitors per Device

Recommended decoupling capacitor quantities for Kintex UltraScale and Virtex UltraScale

devices are listed in Tabl e 1- 2 and Ta ble 1-3 . Decoupling capacitor quantities for

Kintex UltraScale+ and Virtex UltraScale+ devices are listed in Table 1-4 and Tabl e 1- 5 .

Decoupling capacitor quantities for Zynq UltraScale+ devices are listed in Tab le 1-9 . The

optimized quantities of PCB decoupling capacitors assume that the voltage regulators have

stable output voltages and meet the regulator manufacturer's minimum output capacitance

requirements.

The assumptions used for the decoupling quantities are shown below. If any of those

assumptions significantly differ from the actual design, simulations are recommended to

determine the actual amount of required capacitance, which could be higher or lower. The

Send Feedback

UltraScale Architecture PCB Design 19

UG583 (v1.16) June 26, 2019 www.xilinx.com

Chapter 1: Power Distribution System in UltraScale Devices

decoupling recommendations are designed for optimal performance between roughly

100 kHz and 10–20 MHz.

Because device capacitance requirements vary with CLB and I/O utilization, PCB decoupling

guidelines are provided on a per-device basis based on very high utilization so as to cover

a majority of use cases. Resource usage consists (in part) of:

• 80% of LUTs and registers at 245 MHz and 25% toggle rate

• 80% block RAM and DSP at 491 MHz and 50% toggle rate

• 50% MMCM and 25% PLL at 500 MHz

• 25% I/O at SSTL 1.2/1.35 at 1200 MHz and 40% toggle rate

• 75% I/O at POD 1.2 at 1200 MHz DDR and 40% toggle rate

An importable XPE file that contains the above usage assumptions in a KU9P FFVE900

device can be downloaded from the Xilinx website.

Step Load Assumptions

Different step loads are assumed for each main voltage rail. The step load is the percentage

of the dynamic current that is expected to be demanded at any given switching event.

Tab l e 1- 1 lists the step load percentage used when calculating device capacitance

requirements.

The slew rate of the switching event is dependent on the design, and can be estimated to be

between 1 ns and 100 ns (or longer). Smaller current designs generally have faster current

slew rates, while larger designs tend to have slower slew rates. A general rule of thumb for

high-current designs can be considered to be 0.25 ns per amp (or 4 A/ns) of step current.

The Xilinx Power Estimator (XPE) tool is used to estimate the current on each power rail.

Kintex UltraScale FPGAs Data Sheet: DC and AC Switching Characteristics (DS892) [Ref 1]

and Virtex UltraScale FPGAs Data Sheet: DC and AC Switching Characteristics (DS893) [Ref 2]

provide the operating range for all the various power rails. The PCB designer should ensure

that the AC ripple plus the DC tolerance of the voltage regulator do not exceed the

operating range.

The capacitor numbers shown in this user guide are based on the following assumptions:

Table 1-1: Step Load for Device Capacitance

Voltage Rail Step Load (%)

CCINT

CCINT_IO

CCBRAM

CCAUX

CCAUX_IO

100

CCO

(HP/HR) 100

Send Feedback

UltraScale Architecture PCB Design 20

UG583 (v1.16) June 26, 2019 www.xilinx.com

Chapter 1: Power Distribution System in UltraScale Devices

CCINT

operating range from the data sheet = 3%;

Assumed DC tolerance = 1%;

Therefore, allowable AC ripple = 3% – 1% = 2%.

The target impedance is calculated using the 2% AC ripple along with the current estimates

from XPE for the above resource utilization to arrive at the capacitor recommendations. The

equation for target impedance is:

Equation 1-1

CCINT

, V

CCAUX

, and V

CCBRAM

capacitors are listed as the quantity per device, while V

CCO

capacitors are listed as the quantity per I/O bank. Device performance at full utilization is

equivalent across all devices when using these recommended networks.

Tab l e 1- 2 through Tab le 1-9 do not provide the decoupling networks required for the GTY

or GTH transceiver power supplies. For this information, refer to the UltraScale Architecture

GTH Transceivers User Guide (UG576) [Ref 6] or the UltraScale Architecture GTY Transceivers

User Guide (UG578) [Ref 7].

RECOMMENDED: Refer to the UltraScale Architecture Schematic Review Checklist (XTP344) [Ref 8] and

UltraScale+ FPGA and Zynq UltraScale+ MPSoC Schematic Review Checklist (XTP427) [Ref 18] for a

comprehensive checklist for schematic review which complements this user guide.

Note: The capacitor values and part numbers have been updated taking into account the latest

product offerings from various vendors because some of the part numbers from the previous

versions of this user guide have reached end of life. The new guidelines also incorporate capacitors

with a wider temperature range (X6S) compared to the previous part numbers, while moving away

from a combination of tantalum/ceramic capacitors to solely ceramic capacitors across the entire

frequency range. The prior capacitor tables and specifications are still valid for existing designs, but

for new designs, the current tables and specifications are recommended.

Recommended Decoupling Capacitor Quantities for Kintex

UltraScale and Virtex UltraScale Devices

Tab l e 1- 2 and Ta b le 1 -3 show the recommended decoupling capacitor quantities for Kintex

UltraScale and Virtex UltraScale devices.

target

VoltageRailValue

% Ripple

100

-----------------------

StepLoadCurrent

--------------------------------------------------------------------------=

Table 1-2: Kintex UltraScale Devices Decoupling Capacitor Recommendations

CCINT

CCINT_IO

(1)

CCBRAM

CCAUX

CCAUX_IO

(2)

HRIO/HPIO

(3)

(per bank)

330 µF 100 µF 47 µF 10 µF 47 µF 10 µF 47 µF 10 µF 47 µF 10 µF

XCKU025-FFVA1156 1 4 1 1 1 1 1 1 1 1

XCKU035-FBVA676 1 5 1 1 1 1 1 1 1 1

XCKU035-SFVA784 1 5 1 1 1 1 1 1 1 1

Send Feedback
