Screening plate fitting PM240-2 PT
M5,
3.5 Nm
Screening plate fitting PM240-2
Air flow distances
abovebelow
Ø 6 mm
mounting frame
fixing hole
FSC
e
e
aaa
aaa
d
c
b
mounting frame
fixing hole
mounting frame
fixing hole
mounting frame
fixing hole
Ø 6 mm
aa
aa
d
FSA/FSB
e
e
c
b
Height
Width
T1
T2
Depth
CU
IOP
Cutouts and drill patterns in
the cabinet wall for the
mounting frame
Drill patterns and dimensions PM240-2, Push Through
IP20 Units
Frame
size
Dimensions (mm)
Distances
(mm)
1)
Fixings
Drill pattern
(mm)
Height
Width
Depth
Max.
depth
with CU
and OP
Above
Below
Screw
Tightening
Torque
(Nm)
a
b
c
With
Shielding
Plate
FSA
196
276
73
165
250
80
100
M4
2.5
186
62.3
6
FSB
291
370
100
165
250
80
100
M4
2.5
281
80
6
FSC
355
432
140
165
250
80
100
M4
3.0
343
120
6
1)
The Power Modules can be mounted side-by-side. Due to tolerance reasons, we recommend a lateral
distance of about 1 mm
PT Units
Frame
size
Dimensions (mm)
Distances
(mm)
1)
Fixings
Drill pattern and cutouts (mm)
Height
Width
Depth
Max.
d
epth
w
ith CU
and OP
Above
Below
Screw
Tightening
T
orque
(Nm)
a
b
c
d
e
With
Shielding
Plate
T1
T2
FSA
238
322
126
171
117.7
53.1
256
80
100
M5
3.5
103
106
88
198
27
FSB
345
430
154
171
117.7
53.1
256
80
100
M5
3.5
147.5
134
116
304
34.5
FSC
411
500
200
171
117.7
53.1
256
80
100
M5
3.5
123
174
156
365
30.5
1)
The Power Modules can be mounted side-by-side. Due to tolerance reasons, we recommend a lateral distance of about 1 mm
Cable lengths, using
EMI Level (Emission)
Screened cables, filtered units (class A)
50 m
Second Environment, C2
Screened cables, unfiltered units,
50 m
EMI Standard not fullfilled
Unscreened cables, filtered or unfiltered units
100 m
EMI Standard not fullfilled
Dimensions and drill patterns PM240-2, IP20
36.5
a
c
b
FSA
a c
b
FSB/FSC
Height
Width
Depth
CU
IOP
IP20 Units
Frame
size
Dimensions (mm)
Distances
(mm)
1)
Fixings
Drill pattern
(mm)
Height
Width
Depth
Max.
d
epth
w
ith CU
and OP
Above
Below
Screw
Tightening
T
orque
(Nm)
a
b
c
With
Shielding
Plate
FSA
196
276
73
165
250
80
100
M4
2.5
186
62.3
6
FSB
291
370
100
165
250
80
100
M4
2.5
281
80
6
FSC
355
432
140
165
250
80
100
M5
3.5
343
120
6
1)
The Power Modules can be mounted side-by-side. Due to tolerance reasons, we recommend a lateral
distance of about 1 mm
PT Units
Frame
size
Dimensions (mm)
Distances
(mm)
1)
Fixings
Drill patt
Height
Width
Depth
Max.
depth
with CU
and OP
Above
Below
Screw
Tightening
Torque
(Nm)
a
With
Shielding
Plate
T1
T2
FSA
238
322
126
171
117.7
53.1
256
80
100
M5
3.0
103
FSB
345
430
154
171
117.7
53.1
256
80
100
M5
3.0
147.5
FSC
411
500
200
171
117.7
53.1
256
80
100
M5
3.0
123
1)
The Power Modules can be mounted side-by-side. Due to tolerance reasons, we recommend a lateral distance of about 1 mm
Cable lengths, using
EMI Level (Emission)
Screened cables, filtered units (class A)
50 m
Second Environment, C2
Screened cables, unfiltered units,
50 m
EMI Standard not fullfilled
Unscreened cables, filtered or unfiltered units
100 m
EMI Standard not fullfilled
Compact Operating Instructions
SINAMICS G120
Power Module PM240-2, FSA, FSB, FSC
*A5E03701335A-08*
接触带电部件会引发生命危险
本设备会传导危险电压。
接触带电部件可能会造成人员重伤，甚至是死亡。
务必遵循变频器手册中的说明。
警告
Pericolo di morte per contatto con parti sotto tensione
In questo apparecchio sono presenti tensioni pericolose.
Il contatto con parti sotto tensione può provocare la morte o gravi lesioni.
Attenersi alle avvertenze contenute nei manuali del rispettivo convertitore.
Avvertenza
Peligro de muerte al tocar piezas bajo tensión
En el presente equipo hay aplicadas tensiones peligrosas.
Tocar piezas que están bajo tensión puede provocar lesiones corporales graves o
incluso la muerte.
Respete las indicaciones que se especifican en los manuales del convertidor
correspondiente.
Advertencia
Danger de mort en cas de contact avec des pièces sous tension
L'appareil présente des tensions électriques dangereuses.
Tout contact avec des parties sous tension peut entraîner la mort ou des blessures
graves.
Respecter les consignes figurant dans les manuels du variateur concerné.
Attention
Danger to life when live parts are touched
The present device conducts hazardous voltages.
Touching live components can result in death or severe injury.
Observe the notes in the manuals of the corresponding converter.
Warning
Lebensgefahr durch Berührung unter Spannung stehende Teile
Das vorliegende Gerät führt gefährliche Spannungen.
Beim Berühren unter Spannung stehender Teile erleiden Sie Tod oder schwere
Körperverletzungen.
Beachten Sie die Hinweise in den Handbüchern des zugehörigen Umrichters.
Warnung
Cabinet
Seal
Mounting Frame
It is recommended that the optional mounting
frame is used to install the Push-through Power
Module in a cabinet. This optional mounting
frame is designed in conjunction with the
supplied seal to easily maintain an IP55 rating of
the enclosure (the seal is delivered with the
Power Module). If the Power Module is mounted
without using the optional Mounting frame, it is
the user’s responsibility to ensure the correct IP
protection rating is reached.
FSA: 6SL3260-6AA00-0DA0
FSB: 6SL3260-6AB00-0DA0
FSC: 6SL3260-6AC00-0DA0
Push-Through mounting frame with
mounting sequence
Declaration of Conformity
The Declaration of Conformity can be found at the following link:
http://support.automation.siemens.com/WW/view/en/30563514/134200
Siemens AG,
Frauenauracher Str. 80,
DE-91056 Erlangen
Issue 09/2015
1
2
2
1
3
3
4
2
M4,
2.5 Nm
