电机描述
1.3 选型和订货数据
异步电机 1PH7 (PM)
20 配置手册, (APH7P), 05/2007, 6SN1197-0AC71-0RP0
1.3 选型和订货数据
Rated
speed
Shaft
height
SH
Rated
power
Rated
torque
Rated
current
Rated
voltage
Speed
during field
weakening
1)
Max. permissi-
ble continuous
speed
2)
Max.
speed
3)
1PH7 asynchronous motor
n
rated
P
rated
M
rated
I
rated
V
rated
n
2
n
S1
n
max
rpm kW/HP Nm/lb
f
-ft A V rpm rpm rpm Order No.
400 V 3 AC line voltage, Servo Control
400 160 9.5/12.7 227/167.3 30 274 1940 3700
9)
6500
9)
1PH7163-
7 7
B
7 7
-
7
. . .
13/17.4 310/228.5 37 294 1540 3700
9)
6500
9)
1PH7167-
7 7
B
7 7
-
7
. . .
1000 100 3.7/5.0 35/25.8 10 343 2250 5500
9)
9000
9)
1PH7103-
7 7
D
7 7
-
7
. . .
6.3/8.5 60/44.2 17.5 319 3560 5500
9)
9000
9)
1PH7107-
7 7
D
7 7
-
7
. . .
132 12/16.1 115/84.8 30 336 2500 4500 8000
9)
1PH7133-
7 7
D
7 7
-
7
. . .
17/22.8 162/119.4 43 322 3390 4500 8000
9)
1PH7137-
7 7
D
7 7
-
7
. . .
160 22/29.5 210/154.8 55 315 2750 3700 6500
9)
1PH7163-
7 7
D
7 7
-
7
. . .
28/37.6 267/196.8 71 312 4090 3700 6500
9)
1PH7167-
7 7
D
7 7
-
7
. . .
1500 100 3.7/5.0 24/17.7 10 350 5360 5500 9000
9)
1PH7101-
7 7
F
7 7
-
7
. . .
5.5/7.4 35/25.8 13 350 3000 5500 9000
9)
1PH7103-
7 7
F
7 7
-
7
. . .
7.0/9.4 45/33.2 17.5 346 5110 5500 9000
9)
1PH7105-
7 7
F
7 7
-
7
. . .
9.0/12.1 57/42 23.5 336 3500 5500 9000
9)
1PH7107-
7 7
F
7 7
-
7
. . .
132 11/14.8 70/51.6 24 350 4310 4500 8000
9)
1PH7131-
7 7
F
7 7
-
7
. . .
15/20.1 96/70.8 34 346 4400 4500 8000
9)
1PH7133-
7 7
F
7 7
-
7
. . .
18.5/24.8
118/87 42 350 4920 4500 8000
9)
1PH7135-
7 7
F
7 7
-
7
. . .
22/29.5 140/103.2 57 308 3750 4500 8000
9)
1PH7137-
7 7
F
7 7
-
7
. . .
160 30/40.2 191/140.8 72 319 4000 3700 6500 1PH7163-
7 7
F
7 7
-
7
. . .
37/49.6 236/173.9 82 350 2750 3700 6500 1PH7167-
7 7
F
7 7
-
7
. . .
2000 100 7/9.4 33/24.3 17.5 343 4630 5500 9000 1PH7103-
7 7
G
7 7
-
7
. . .
10.5/14.1
50/36.9 26 350 4000 5500 9000 1PH7107-
7 7
G
7 7
-
7
. . .
132 20/26.8 96/70.8 45 350 4000 4500 8000 1PH7133-
7 7
G
7 7
-
7
. . .
28/37.6 134/98.8 60 350 3750 4500 8000 1PH7137-
7 7
G
7 7
-
7
. . .
160 36/48.3 172/126.8 85 333 3000 3700 6500 1PH7163-
7 7
G
7 7
-
7
. . .
41/55.0 196/144.5 89 350 2750 3700 6500 1PH7167-
7 7
G
7 7
-
7
. . .
Fan: External fan unit, heavy-gauge threaded cable entry in terminal box
Without external fan unit, for pipe connection, heavy-gauge threaded cable entry in terminal box
External fan unit, metric cable entry in terminal box
Without external fan unit, for pipe connection, metric cable entry in terminal box
2
6
7
8
Encoder systems
for motors without
DRIVE-CLiQ interface:
Without encoder
Absolute encoder EnDat 2048 pulses/revolution
Incremental encoder HTL 1024 pulses/revolution
Incremental encoder HTL 2048 pulses/revolution
Incremental encoder sin/cos 1 V
pp
with C and D tracks
Incremental encoder sin/cos 1 V
pp
without C and D tracks
2-pole resolver
A
E
H
J
M
N
R
Encoder systems
for motors with
DRIVE-CLiQ interface:
Absolute encoder 22-bit Singleturn + 12-bit Multiturn
Incremental encoder 22-bit with commutation position
Incremental encoder 22-bit
Resolver 14-bit
F
D
Q
P
Terminal box/
cable entry
(view onto DE):
Top/from right
Top/from NDE
Top/from left
0
2
3
Type: IM B3 (IM V5, IM V6)
IM B5 (IM V1, IM V3) available only for shaft heights 100 and 132
IM B35 (IM V15, IM V36)
0
2
3
Holding brake
with emergency stop
function
4)
:
Without brake 0
Brake supply
voltage
230 V 1 AC, 50/60 Hz
With brake
With brake (includes microswitch)
With brake (includes manual release)
With brake (includes manual release and microswitch)
1
2
3
4
Brake
supply voltage
24 V DC
With brake
With brake (includes microswitch)
With brake (includes manual release)
With brake (includes manual release and microswitch)
5
6
7
8
