In alignment with PPAP 4.0, an "organization" is the manufacturing site of external suppliers manufacturing
production or service parts and products for Ford Motor Company. The sub-tier supplier is the manufacturing
facility contracted by the organization to ship product to the organization in support of a Ford Motor Company
contract. Special situations may apply where the organization is directed by Ford to contract a particular sub-
tier supplier. Please contact the Ford buyer to understand the organization responsibilities where sub-tier
suppliers are directed by Ford.
In this document, the terms "organization" and “tier 1 supplier" are interchangeable, both representing the tier 1
site manufacturing production or service parts for Ford Motor Company.
2 Submission of PPAP (PPAP section 1.1)
The organization shall submit PPAP per Ford's Phased PPAP, available at
https://web.qpr.ford.com/sta/Phased_PPAP.html, through the Ford Supplier Portal.
3 Design Record (PPAP – section 2.2.1)
For a Design Record to be acceptable, the following conditions must exist:
• Records shall be released and authorized for production and/or service use in the appropriate Ford design
system (i.e., Production Authority level in WERS – Worldwide Engineering Release System, Teamcenter).
• Supporting product data (as mastered) shall comply with the Ford Engineering CAD and Drafting
Standards (FECDS) available via the Ford Supplier Portal
https://team.extsp.ford.com/sites/C3PNGMethods/C3PNGMethods.html
• Design records shall be authored within corporate data repositories (i.e. WERS, Teamcenter, FordDoc) as
required by Ford Product Development Engineering, and records shall fully align (i.e.
WERS/CAD/drawing/Ford Purchase Order)
• As part of the design record and where specified by Ford PD, organizations that supply electrical
components shall include current Device Transmittal information as defined by the Ford Device
Transmittals Engineering Standard (via the Ford Design and Release Engineer).
When reviewing Design Record requirements, the drawing notes are also to be reviewed by the organization
and evidence of conformance provided.
Service parts requirements
Packaged Service Parts
Packaging: All organizations supplying service parts to North America shall comply with FCSD (Ford
Customer Service Division) Packaging and Shipping requirements. The Packaging and Shipping Guidelines
can be accessed at: http://web.pkginfo.ford.com through the Ford Supplier Portal. All other regions shall
comply with local requirements; contact your regional FCSD STA engineer for details.
Rust: All organizations supplying service parts to North America shall comply with FCSD (Ford Customer
Service Division) rust policy. The Packaging and Shipping Guidelines can be accessed at:
http://web.pkginfo.ford.com through the Ford Supplier Portal. Organizations supplying FCSD Asia Pacific,
FCSD Europe and FCSD South America shall comply with local requirements, contact your regional FCSD
STA engineer for details.
Service Kits with Packaged Chemical Components: FCSD (Ford Customer Service Division) Package
Material Specification L1794 (Labeling Instructions for Kits with Chemical/Regulated Components) will be
specified on the individual service kit’s packaging specification. The L1794 requires the chemical component
tier 1 supplier and/or FCSD Contract Packager to develop the appropriate warning label for these products. The
FIR # (FIR #: "Ford Internal Reference Number" also known as Toxicology Number) must be included on the
tier 1 supplier developed warning label for the packaged chemical components, e.g. greases, lubricants,
adhesives, solvents, butyl tape, etc. The L1794 label Package Material Specification can be found at:
http://web.pkginfo.ford.com/specs/specspdf/specs06/l1794.pdf through the Ford Supplier Portal.
Dry Friction Materials: A unique FCSD developed toxicology label or a generic toxicology label will be
specified on individual dry friction service part’s packaging specifications. The generic label for brake and
clutch parts will be L1853. The Package Material Specification for L1853 can be found at
https://web.pkginfo.ford.com/specs/specspdf/specs06/l1853.pdf through the Ford Supplier Portal. Uniquely
developed toxicology labels will have their own label number specified on the parts packaging specification.
