Fast, flexible, highly reliable
image acquisition
The X64-CL Express is a Camera Link
®
frame grabber that is based on the PCI Express x1
interface—next generation bus interface technology for the host PCs. PCI-Express is a
serial digital interface technology that is specifically designed to offer dedicated bandwidth
to each plug-in device while reducing the PCB design complexity.
The X64-CL Express supports up to two independent Base or one Medium Camera Link
colour and/or monochrome cameras. Its low cost, combined with its ability to reformat input
data from multi-tap area and line scan cameras in addition to its on-board FPGA based
processing (including Bayer decoding and real-time shading correction) makes the X64-CL
Express an ideal solution for a wide variety of cost-sensitive applications where flexibility,
performance, and reliability cannot be compromised.
Teledyne DALSA Platform Development Advantage - Free Run-Time Licensing
The Sapera Essential standard processing tool run-time license is offered at no additional charge
when combined with the Teledyne DALSA frame grabbers. This software run-time license
1
includes
access to over 400 image processing functions, area-based (normalized correlation based)
template matching tool, blob analysis and lens correction tool.
Teledyne DALSA Platform Development Advantage - Free Run-Time Licensing
The Sapera Essential standard processing tool run-time license is offered at no additional charge
when combined with the Teledyne DALSA frame grabbers. This software run-time license
1
includes
access to over 400 image processing functions, area-based (normalized correlation based)
template matching tool, blob analysis and lens correction tool.
1
Some conditions and limitations apply, contact Teledyne DALSA sales for details.
Key Features
• Half-lengthPCIExpressx1board
• SupportsWindowsx64-bit
• Simultaneousacquisitionfromtwo
Camera Link base cameras
• FPGAbasedprocessingincludingBayer
decoding and shading correction
• SupportsfieldprovenTrigger-to-Image
Reliability framework
• Acquisitionpixelclockratesupto
85MHz
• Lowcosttohighperformanceratio
• TeledyneDALSAPlatformDevelopment
Advantage – Free Run-time Licensing
1
X64-CL Express
TM
