S
C
P
H
-
70000
se
r
i
es
K
-
c
h
ass
i
s
Reproduction Prohibited
SAFTY-RELATED COMPONENT WARNING!!
C
O
MPONENTS IDENTIFIED BY MARK OR DOTTED
LINE WITH MARK ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPE
RA
TIO
N, REPLACE THESE COMPONENTS WITH
SO
N
Y PARTS WHOSE PART NUMBERS ARE APPEAR AS
S
H
OWN IN THIS MANUAL OR IN SUPPLEMENTS
P
UB
LISHED BY SONY.
CAU
TIO
N
:
The use of optical instrument with this product will increase eye
hazard.
CAU
TIO
N
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
S
A
FETY
CH
E
CK
-
O
U
T
After correcting the original service problem, perform the following safety
checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes
and bridges.
2. Check the interboard wiring to ensure that no wires are
“pinched” or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous repair. Point
them out to the customer and recommend their replacement.
4. Look for parts which, though functioning, show obvious signs
of deterioration. Point them out to the customer and
recommend their replacement.
5. Check the line cord for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
6. Check the B+ voltage to see it is at the values specified.
7. Check the metal trim, “metallized” knobs, screws, and all other
exposed metal parts for AC leakage.
Check leakage as described right.
1.5 k
Z
0.15 µF
AC
voltmeter
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground
Fig.A. Using an AC voltmeter to check AC leakage.
LE
AKA
GE TEST
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microampers.).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instruments.
2. A battery-operated AC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The “limit”
indication is 0.75 V, so analog meters must have an accurate
low-voltage scale. The Simpson 250 and Sanwa SH-63Trd are
examples of a passive VOM that is suitable. Nearly all battery
operated digital multimeters that have a 2 V AC range are
suitable. (See Fig. A)
W
ARN
I
N
G
!!
W
H
E
N
SERVICING , DO NOT APPROACH THE LASER
EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS
N
ECESSARY TO CONFIRM LASER BEAM EMISSION,
B
E SURE TO OBSERVE FROM A DISTANCE OF MORE
THAN 25cm FROM THE SERFACE OF THE OBJECTIVE
LE
N
S ON THE OPTICAL PICK-UP BLOCK.
CAU
TIO
N
The use of optical instruments with this product will increase eye
hazard. As the laser beam used in this CD/DVD ROM Drive is
harmful to eyes, do not attempt disassemble the cabinet.
Refer servicing to qualified personnel only.
This appliance is classified as a CLASS 1 LASER product.
CAU
TIO
N
Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the
manufacturer.
Discard used batteries according to the manufacturer’s
instructions.
L
i
t
hiu
m
B
a
tt
e
r
i
es
If an equipment is provided with a replaceable lithium battery, the
following applies:
– if the battery is placed in an OPERATOR ACCESS AREA,
there shall be a warning close to the battery or in both the
operating and the service instructions:
– if the battery is placed elsewhere in the equipment, there shall
be a warning close to the battery or in the service instructions.
