Features
•
80C52 Compatible
– 8051 Instruction Compatible
– Six 8-bit I/O Ports (64 Pins or 68 Pins Versions)
– Four 8-bit I/O Ports (44 Pins Version)
– Three 16-bit Timer/Counters
– 256 Bytes Scratch Pad RAM
– 9 Interrupt Sources with 4 Priority Levels
•
Integrated Power Monitor (POR/PFD) to Supervise Internal Power Supply
•
ISP (In-System Programming) Using Standard V
CC
Power Supply
•
2048 Bytes Boot ROM Contains Low Level Flash Programming Routines and a Default
Serial Loader
•
High-speed Architecture
– In Standard Mode:
• 40 MHz (Vcc 2.7V to 5.5V, both Internal and external code execution)
• 60 MHz (Vcc 4.5V to 5.5V and Internal Code execution only)
– In X2 mode (6 Clocks/machine cycle)
• 20 MHz (Vcc 2.7V to 5.5V, both Internal and external code execution)
• 30 MHz (Vcc 4.5V to 5.5V and Internal Code execution only)
•
64K Bytes On-chip Flash Program/Data Memory
– Byte and Page (128 Bytes) Erase and Write
– 100k Write Cycles
•
On-chip 1792 bytes Expanded RAM (XRAM)
– Software Selectable Size (0, 256, 512, 768, 1024, 1792 Bytes)
– 768 Bytes Selected at Reset for T89C51RD2 Compatibility
•
On-chip 2048 Bytes EEPROM Block for Data Storage (AT89C51ED2 Only)
•
100K Write Cycles
•
Dual Data Pointer
•
Variable Length MOVX for Slow RAM/Peripherals
•
Improved X2 Mode with Independent Selection for CPU and Each Peripheral
•
Keyboard Interrupt Interface on Port 1
•
SPI Interface (Master/Slave Mode)
•
8-bit Clock Prescaler
•
16-bit Programmable Counter Array
– High Speed Output
– Compare/Capture
– Pulse Width Modulator
– Watchdog Timer Capabilities
•
Asynchronous Port Reset
•
Full-duplex Enhanced UART with Dedicated Internal Baud Rate Generator
•
Low EMI (Inhibit ALE)
•
Hardware Watchdog Timer (One-time Enabled with Reset-Out), Power-off Flag
•
Power Control Modes: Idle Mode, Power-down Mode
•
Single Range Power Supply: 2.7V to 5.5V
•
Industrial Temperature Range (-40 to +85°C)
•
Packages: PLCC44, VQFP44, PLCC68, VQFP64
8-bit Flash
Microcontroller
AT89C51RD2
AT89C51ED2
3个16位定时器
9个独立中断,4个中断优先级
2Kbyte boot ROM
64KByte 程序存储区
1792Byte 变量存储区

2
4235K–8051–05/08
AT89C51RD2/ED2
1. Description
AT89C51RD2/ED2 is high performance CMOS Flash version of the 80C51 CMOS single chip 8-
bit microcontroller. It contains a 64-Kbyte Flash memory block for code and for data.
The 64-Kbytes Flash memory can be programmed either in parallel mode or in serial mode with
the ISP capability or with software. The programming voltage is internally generated from the
standard V
CC
pin.
The AT89C51RD2/ED2 retains all of the features of the Atmel 80C52 with 256 bytes of internal
RAM, a 9-source 4-level interrupt controller and three timer/counters. The AT89C51ED2 pro-
vides 2048 bytes of EEPROM for nonvolatile data storage.
In addition, the AT89C51RD2/ED2 has a Programmable Counter Array, an XRAM of 1792
bytes, a Hardware Watchdog Timer, SPI interface, Keyboard, a more versatile serial channel
that facilitates multiprocessor communication (EUART) and a speed improvement mechanism
(X2 Mode).
The fully static design of the AT89C51RD2/ED2 allows to reduce system power consumption by
bringing the clock frequency down to any value, including DC, without loss of data.
The AT89C51RD2/ED2 has 2 software-selectable modes of reduced activity and an 8-bit clock
prescaler for further reduction in power consumption. In the Idle mode the CPU is frozen while
the peripherals and the interrupt system are still operating. In the Power-down mode the RAM is
saved and all other functions are inoperative.
The added features of the AT89C51RD2/ED2 make it more powerful for applications that need
pulse width modulation, high speed I/O and counting capabilities such as alarms, motor control,
corded phones, and smart card readers.
Table 1-1. Memory Size and I/O Pins
Package Flash (Bytes) XRAM (Bytes) Total RAM (Bytes) I/O
PLCC44/VQFP44 64K 1792 2048 34
PLCC68/VQFP64 64K 1792 2048 50

3
4235K–8051–05/08
AT89C51RD2/ED2
2. Block Diagram
Figure 2-1. Block Diagram
Timer 0
INT
RAM
256x8
T0
T1
RxD
TxD
WR
RD
EA
PSEN
ALE/
XTALA2
XTALA1 EUART
CPU
Timer 1
INT1
Ctrl
INT0
(2)
(2)
C51
CORE
(2) (2) (2) (2)
Port 0
P0
Port 1
Port 2
Port 3
P1
P2
P3
XRAM
1792 x 8
IB-bus
PCA
RESET
PROG
Watch
-dog
PCA
ECI
VSS
VCC
(2)(2)
(1)
(1): Alternate function of Port 1
(2): Alternate function of Port 3
(1)
Timer2
T2EX
T2
(1) (1)
Flash
64K x 8
Keyboard
(1)
Keyboard
MISO
MOSI
SCK
SS
Port4
P4
(1)
(1)
(1)
(1)
BOOT
2K x 8
ROM
Regulator
POR / PFD
Port 5
P5
Parallel I/O Ports &
External Bus
SPI
EEPROM*
2K x 8
(AT89C51ED2)

4
4235K–8051–05/08
AT89C51RD2/ED2
3. SFR Mapping
The Special Function Registers (SFRs) of the AT89C51RD2/ED2 fall into the following
categories:
• C51 core registers: ACC, B, DPH, DPL, PSW, SP
• I/O port registers: P0, P1, P2, P3, PI2
• Timer registers: T2CON, T2MOD, TCON, TH0, TH1, TH2, TMOD, TL0, TL1, TL2, RCAP2L,
RCAP2H
• Serial I/O port registers: SADDR, SADEN, SBUF, SCON
• PCA (Programmable Counter Array) registers: CCON, CCAPMx, CL, CH, CCAPxH, CCAPxL
(x: 0 to 4)
• Power and clock control registers: PCON
• Hardware Watchdog Timer registers: WDTRST, WDTPRG
• Interrupt system registers: IE0, IPL0, IPH0, IE1, IPL1, IPH1
• Keyboard Interface registers: KBE, KBF, KBLS
• SPI registers: SPCON, SPSTR, SPDAT
• BRG (Baud Rate Generator) registers: BRL, BDRCON
• Clock Prescaler register: CKRL
• Others: AUXR, AUXR1, CKCON0, CKCON1
Table 3-1. C51 Core SFRs
Mnemonic Add Name 7 6 5 4 3 2 1 0
ACC E0h Accumulator
B F0h B Register
PSW D0h Program Status Word CY AC F0 RS1 RS0 OV F1 P
SP 81h Stack Pointer
DPL 82h Data Pointer Low Byte
DPH 83h Data Pointer High Byte
Table 3-2. System Management SFRs
Mnemonic Add Name 7 6 5 4 3 2 1 0
PCON 87h Power Control SMOD1 SMOD0 - POF GF1 GF0 PD IDL
AUXR 8Eh Auxiliary Register 0 DPU - M0 XRS2 XRS1 XRS0 EXTRAM AO
AUXR1 A2h Auxiliary Register 1 - - ENBOOT - GF3 0 - DPS
CKRL 97h Clock Reload Register - - - - - - - -
CKCKON0 8Fh Clock Control Register 0 - WDTX2 PCAX2 SIX2 T2X2 T1X2 T0X2 X2
CKCKON1 AFh Clock Control Register 1 - - - - - - - SPIX2

5
4235K–8051–05/08
AT89C51RD2/ED2
Table 3-3. Interrupt SFRs
Mnemonic Add Name 7 6 5 4 3 2 1 0
IEN0 A8h Interrupt Enable Control 0 EA EC ET2 ES ET1 EX1 ET0 EX0
IEN1 B1h Interrupt Enable Control 1 - - - - - ESPI KBD
IPH0 B7h Interrupt Priority Control High 0 - PPCH PT2H PHS PT1H PX1H PT0H PX0H
IPL0 B8h Interrupt Priority Control Low 0 - PPCL PT2L PLS PT1L PX1L PT0L PX0L
IPH1 B3h Interrupt Priority Control High 1 - - - - - SPIH KBDH
IPL1 B2h Interrupt Priority Control Low 1 - - - - - SPIL KBDL
Table 3-4. Port SFRs
Mnemonic Add Name 7 6 5 4 3 2 1 0
P0 80h 8-bit Port 0
P1 90h 8-bit Port 1
P2 A0h 8-bit Port 2
P3 B0h 8-bit Port 3
P4 C0h 8-bit Port 4
P5 E8h 8-bit Port 5
P5 C7h 8-bit Port 5 (byte addressable)
Table 3-5. Timer SFRs
Mnemonic Add Name 7 6 5 4 3 2 1 0
TCON 88h Timer/Counter 0 and 1 Control TF1 TR1 TF0 TR0 IE1 IT1 IE0 IT0
TMOD 89h Timer/Counter 0 and 1 Modes GATE1 C/T1# M11 M01 GATE0 C/T0# M10 M00
TL0 8Ah Timer/Counter 0 Low Byte
TH0 8Ch Timer/Counter 0 High Byte
TL1 8Bh Timer/Counter 1 Low Byte
TH1 8Dh Timer/Counter 1 High Byte
WDTRST A6h WatchDog Timer Reset
WDTPRG A7h WatchDog Timer Program - - - - - WTO2 WTO1 WTO0
T2CON C8h Timer/Counter 2 control TF2 EXF2 RCLK TCLK EXEN2 TR2 C/T2# CP/RL2#
T2MOD C9h Timer/Counter 2 Mode - - - - - - T2OE DCEN
RCAP2H CBh
Timer/Counter 2 Reload/Capture
High Byte
RCAP2L CAh
Timer/Counter 2 Reload/Capture
Low Byte
TH2 CDh Timer/Counter 2 High Byte
