RTL8822BS模块BL-M8822BS1

BL-M8822BS1 module design is based on RTL8822BS-CG solution, The Realtek RTL8822BS-CG is a

highly integrated single-chip that support 2-stream 802.11ac solutions with Multi-user MIMO

(Multiple-Input, Multiple-Output) with integrated Bluetooth 2.1/3.0/4.1 controller,SDIO (SDIO 1.1/2.0/3.0)

interface, and HS-UART mixed interface. It combines a WLAN MAC, a 2T2R capable WLAN baseband,

and RF in s single chip. The RTL8822BS-CG provides a complete solution for a high-performance

integrated wireless and Bluetooth device.

The general HW architecture for the module is shown in Figure 1.

Figure 1

_ IEEE Std. 802.11ac

_ BT 2.1/3.0/4.1
