Rev. 1.00 1 April 18, 2013 Rev. 1.00 PB April 18, 2013
HT75xx-3
100mA Low Power LDO
Features
• Lowpowerconsumption
• Lowvoltagedrop
• Lowtemperaturecoefcient
• Highinputvoltage(upto30V)
• Quiescentcurrent1μA
• Highoutputcurrent:100mA
• Outputvoltageaccuracy:tolerance±2%
• TO92,SOT89andSOT23-5packages
Applications
• Battery-poweredequipment
• Communicationequipment
• Audio/Videoequipment
General Description
TheHT75xx-3seriesisasetofthree-terminal
lowpowerhighvoltageimplementedinCMOS
technology.Theycandeliver100mAoutputcurrent
andallowaninputvoltageashighas30V.Theyare
availablewithseveralfixedoutputvoltagesranging
from2.1Vto12.0V.CMOStechnologyensureslow
voltagedropandlowquiescentcurrent.
Althoughdesignedprimarilyasfixedvoltage
regulators,thesedevicescanbeusedwithexternal
componentstoobtainvariablevoltagesandcurrents.
Selection Table
Part No. Output Voltage Package Marking
HT7521-3 2.1V
TO92
SOT89
SOT23-5
75xx-3 (for TO92)
75xx-3 (for SOT89)
5xx3 (for SOT23-5)
HT7523-3 2.3V
HT7525-3 2.5V
HT7527-3 2.7V
HT7530-3 3.0V
HT7533-3 3.3V
HT7536-3 3.6V
HT7540-3 4.0V
HT7544-3 4.4V
HT7550-3 5.0V
HT7560-3 6.0V
HT7570-3 7.0V
HT7580-3 8.0V
HT7590-3 9.0V
HT75A0-3 10.0V
HT75C0-3 12.0V
Note:″xx″standsforoutputvoltages.
捷多邦,您值得信赖的PCB打样专家!

Rev. 1.00 2 April 18, 2013
HT75xx-3
Block Diagram
Pin Assignment
AbsolutemAximum Ratings
SupplyVoltage................................................. −0.3Vto33V
StorageTemperature.................................... −50°Cto125°C
OperatingTemperature.................................. −40°Cto85°C
Note:Thesearestressratingsonly.Stressesexceedingtherangespeciedunder″AbsolutemAximumRatings″
maycausesubstantialdamagetothedevice.Functionaloperationofthisdeviceatotherconditionsbeyond
thoselistedinthespecificationisnotimpliedandprolongedexposuretoextremeconditionsmAyaffect
devicereliability.
Thermal Information
Symbol Parameter Package Max. Unit
θ
JA
Thermal Resistance (Junction to Ambient)
(Assume no ambient airow, no heat sink)
SOT23-5 500 °C/W
SOT89 200 °C/W
TO92 200 °C/W
P
D
Power Dissipation
SOT23-5 0.20 W
SOT89 0.50 W
TO92 0.50 W
Note:P
D
ismeasuredatTa=25°C

Rev. 1.00 3 April 18, 2013
HT75xx-3
Pin Descriptions
Pin No. Pin Name Pin Description
1 GND Ground pin
2 VIN Input pin
3 VOUT Output pin
Electrical Characteristics
HT7521-3, +2.1V Output Type
Ta=25°C
Symbol Parameter
Test Conditions
Min. Typ. Max. Unit
Conditions
V
IN
Input Voltage — — — 30 V
V
OUT
Output Voltage Tolerance V
IN
=V
OUT
+2V, I
OUT
=10mA 2.058 2.100 2.142 V
I
OUT
Output Current V
IN
=V
OUT
+2V 70 100 — mA
∆V
OUT
Load Regulation V
IN
=V
OUT
+2V, 1mA≤I
OUT
≤50mA — 25 60 mV
V
DIF
Dropout Voltage I
OUT
=1mA, ∆V
O
=2% — 30 100 mV
I
SS
Quiescent Current No load — 1.0 1.5 μA
Line Regulation V
O
+1V≤V
IN
≤30V, I
OUT
=1mA — — 0.2 %/V
Temperature Coefcient I
OUT
=10mA, -40°C<T
a
<85°C — 100 — ppm/°C
Note:Dropoutvoltageisdenedastheinputvoltageminustheoutputvoltagethatproducesa2%changeinthe
outputvoltagefromthevalueatV
IN
=V
OUT
+2Vwithaxedload.
HT7523-3, +2.3V Output Type
Ta=25°C
Symbol Parameter
Test Conditions
Min. Typ. Max. Unit
Conditions
V
IN
Input Voltage — — — 30 V
V
OUT
Output Voltage Tolerance V
IN
=V
OUT
+2V, I
OUT
=10mA 2.254 2.300 2.346 V
I
OUT
Output Current V
IN
=V
OUT
+2V 70 100 — mA
∆V
OUT
Load Regulation V
IN
=V
OUT
+2V, 1mA≤I
OUT
≤50mA — 25 60 mV
V
DIF
Dropout Voltage I
OUT
=1mA, ∆V
O
=2% — 30 100 mV
I
SS
Quiescent Current No load — 1.0 1.5 μA
Line Regulation V
O
+1V≤V
IN
≤30V, I
OUT
=1mA — — 0.2 %/V
Temperature Coefcient I
OUT
=10mA, -40°C<Ta<85°C — 100 — ppm/°C
Note:Dropoutvoltageisdenedastheinputvoltageminustheoutputvoltagethatproducesa2%changeinthe
outputvoltagefromthevalueatV
IN
=V
OUT
+2Vwithaxedload.

Rev. 1.00 4 April 18, 2013
HT75xx-3
HT7525-3, +2.5V Output Type
Ta=25°C
Symbol Parameter
Test Conditions
Min. Typ. Max. Unit
Conditions
V
IN
Input Voltage — — — 30 V
V
OUT
Output Voltage Tolerance V
IN
=V
OUT
+2V, I
OUT
=10mA 2.450 2.500 2.550 V
I
OUT
Output Current V
IN
=V
OUT
+2V 70 100 — mA
∆V
OUT
Load Regulation V
IN
=V
OUT
+2V, 1mA≤I
OUT
≤50mA — 25 60 mV
V
DIF
Dropout Voltage I
OUT
=1mA, ∆V
O
=2% — 30 100 mV
I
SS
Quiescent Current No load — 1.0 1.5 μA
Line Regulation V
O
+1V≤V
IN
≤30V, I
OUT
=1mA — — 0.2 %/V
Temperature Coefcient I
OUT
=10mA, -40°C<T
a
<85°C — 100 — ppm/°C
Note:Dropoutvoltageisdenedastheinputvoltageminustheoutputvoltagethatproducesa2%changeinthe
outputvoltagefromthevalueatV
IN
=V
OUT
+2Vwithaxedload.
HT7527-3, +2.7V Output Type
Ta=25°C
Symbol Parameter
Test Conditions
Min. Typ. Max. Unit
Conditions
V
IN
Input Voltage — — — 30 V
V
OUT
Output Voltage Tolerance V
IN
=V
OUT
+2V, I
OUT
=10mA 2.646 2.700 2.754 V
I
OUT
Output Current V
IN
=V
OUT
+2V 70 100 — mA
∆V
OUT
Load Regulation V
IN
=V
OUT
+2V, 1mA≤I
OUT
≤50mA — 25 60 mV
V
DIF
Dropout Voltage I
OUT
=1mA, ∆V
O
=2% — 30 100 mV
I
SS
Quiescent Current No load — 1.0 1.5 μA
Line Regulation V
O
+1V≤V
IN
≤30V, I
OUT
=1mA — — 0.2 %/V
Temperature Coefcient I
OUT
=10mA, -40°C<T
a
<85°C — 100 — ppm/°C
Note:Dropoutvoltageisdenedastheinputvoltageminustheoutputvoltagethatproducesa2%changeinthe
outputvoltagefromthevalueatV
IN
=V
OUT
+2Vwithaxedload.
