线性代数与图论：矩阵方法在图论中的应用

需积分: 10 28 浏览量更新于2023-07-05 收藏 973KB PDF 举报

"Graphs and Matrices" 是一本专注于图论与矩阵理论相互结合的书籍，作者通过线性代数和矩阵理论的方法探讨了图论中的重要结果。这本书旨在展示线性代数在图论研究中的核心作用，尽管在传统上，图论学者可能对使用线性代数持保留态度。书中的内容通常被归类于代数图论领域，参考了Biggs和Godsil及Royle的经典著作，但本书更加侧重于矩阵技术的应用，因此可以称为“线性代数图论”。在图论中，图是由顶点和边构成的数学结构，用于表示各种关系或网络。矩阵则是一种二维数组，常用于表示图的结构和性质。例如，邻接矩阵可以用来表示图中两个顶点之间是否存在边，而度矩阵记录了每个顶点的邻接边的数量。这些矩阵是分析图的连通性、循环、哈密顿路径等问题的关键工具。线性代数在图论中的应用包括但不限于以下方面： 1. **谱图论**：谱理论研究图的特征值和特征向量，这与图的性质紧密相关。例如，图的拉普拉斯矩阵的特征值可以提供关于图的连通性、奇环数和最小生成树的信息。 2. **图的分解**：矩阵分解如奇异值分解(SVD)和特征分解可用于图的分解，揭示图的结构信息，如图的聚类和社区结构。 3. **图的相似性和距离**：通过比较两个图的矩阵表示，可以计算它们之间的相似度或距离，这在图形数据挖掘和网络分析中有重要应用。 4. **遍历矩阵**：遍历矩阵用于描述随机游走过程在图上的行为，有助于理解网络的可达性和扩散过程。 5. **最优化问题**：线性规划和矩阵优化方法可以解决图论中的问题，如最小费用流、最大流和最小割。 6. **图的同构**：矩阵的等价性可以用来判断两个图是否同构，即它们在顶点重新排列后是否相同。 7. **动力系统和稳定性**：在动态网络中，矩阵常被用来描述系统的演化，其特征值和特征向量影响着系统的稳定性和动力学行为。 8. **图的生成树**：矩阵方法也可以用来寻找图的生成树，比如使用Prim算法或Kruskal算法的矩阵版本。此外，书中可能还会涵盖更复杂的主题，如图的谱半径、Fiedler向量（用于社区检测）、图的奇偶分解以及与图相关的矩阵的对角化问题。通过对这些概念的深入理解，读者能够掌握利用线性代数工具解决复杂图论问题的能力。这本书适合对图论和线性代数有基础了解，并希望进一步探索两者交叉领域的读者。

展开

1.2 Eigenvalues of symmetric matrices 5

1.2 Eigenvalues of symmetric matrices

Characteristic polynomial

Let A be an n ×n matrix. The determinant det(A −λ I) is a polynomial in the (com-

plex) variable λ of degree n and is called the characteristic polynomial of A. The

equation

det(A −λ I) = 0

is called the characteristic equation of A. By the fundamental theorem of algebra

the equation has n complex roots and these roots are called the eigenvalues of A.

We remark that it is customary to deﬁne the characteristic polynomial of A as

det(λ I −A) as well. This does not affect the eigenvalues.

The eigenvalues might not all be distinct. The number of times an eigenvalue

occurs as a root of the characteristic equation is called the algebraic multiplicity of

the eigenvalue.

We may factor the characteristic polynomial as

det(A −λ I) = (λ

−λ)···(λ

−λ).

The geometric multiplicity of the eigenvalue λ of A is deﬁned to be the dimension

of the null space of A −λ I. The geometric multiplicity of an eigenvalue does not

exceed its algebraic multiplicity.

If A and B are matrices of order m×n and n ×m, respectively, where m ≥ n, then

the eigenvalues of AB are the same as the eigenvalues of BA, along with 0 with a

(possibly further) multiplicity of m −n.

If λ

,..., λ

are the eigenvalues of A, then det A = λ

···λ

, while trace A =

+ ···+ λ

A principal submatrix of a square matrix is a submatrix formed by a set of rows

and the corresponding set of columns. A principal minor of A is the determinant of

a principal submatrix. A leading principal minor is a principal minor involving rows

and columns 1,..., k for some k.

The sum of the products of the eigenvalues, of A, taken k at a time, equals the

sum of the k ×k principal minors of A. When k = 1 this reduces to the familiar fact

that the sum of the eigenvalues equals the trace.

If λ

,..., λ

are the eigenvalues of the n×n matrix A, and if q(A) is a polynomial

in A, then the eigenvalues of q(A) are q(λ

),..., q(λ

If A is an n ×n matrix with the characteristic polynomial p(A), then the Cayley–

Hamilton theorem asserts that p(A) = 0. The monic polynomial q(A) of minimum

degree that satisﬁes q(A) = 0 is called the minimal polynomial of A.

Spectral theorem

A square matrix A is called symmetric if A = A

. The eigenvalues of a symmetric

matrix are real. Furthermore, if A is a symmetric n ×n matrix, then according to the
